30KW Tethered DC 48 Amp EV Charger For Electric Car

Price Negotiable

Price: USD35000~55000/unit

MOQ: 1unit

Delivery Time: 25days

Brand: SYEV

Product Description

30KW EV Car DC Charger Electric Car Charger Applied For Charging Stations

Techanical Ratings
AC Input
Connection type		U/V/W+N+PE
Input voltage		400V±10%
Input frequency		50Hz/60Hz±10%
Rated power		30kW
Max input current		45A
Power factor		≥0.98, Maximum value
THDi		<5%, Best case
Max. efficiency		>94%
DC Output
Charging interface		Port A: CCS2 Port B: CCS2, IEC 62196-3, DIN70121
Communication with EV		DIN 70121, ISO 15118
Output voltage range		200-1000Vdc
DC Output - When both guns are used for charging at the same time
Maximum output current		75A , each gun
Rated output voltage1		400Vdc
DC output 一 When only single gun is used
Maximum output current		750A
Maximum output power*		30kW
HMI
Touch screen		8-inch touch screen
RFID2		IEC/ISO14443A/B, Mifare/Felica optional
Payment terminal		Nayax VPOS touch
Network		4G modem, Ethernet port *1
Protocol for backend3		OCPP 1.6J
Ambient Conditions
Operating temp, range		-10°C~+50°C
Operating humidity		5-95%
Operating altitude		≤2000m
Mechanical Data
Dimension (WDnf		707560217mm
Degree of protection		IP54
Cooling method		Force air cooling
Charging cable length		5.0m
Noise level		≤75dB
Weight		35.3kg
Standard and Compliance
Standard		IEC 61851-1, IEC 61851-23, IEC 61851-24, IEC 62619-3
		IEC 61851-21-2, IEC 61800-2, IEC 61800-4
Certification mark		TUV CE
