Cylinder Catalyst High Pressure Catalyst For Methanol Synthesis

                                             SAL-112 High-pressure Methanol Synthesis Catalyst Basic Chemicals

SAL-112 High-pressure Methanol Synthesis Catalyst

Description

Model:SAL-112

The High-pressure Methanol Synthesis Catalyst SAL-112 is a kind of Cu-Zn-Al based methanol synthesis catalyst for using coal, oil field gas, refinery gas, coke oven gas, naphtha, natural gas or oil as it’s feedstock. The synthesis plant pressure is12 ~ 32Mpa.

The main reactions are as follows:

CO + 2H2→ CH3OH + 90.69 KJ/mol

CO2 + 3H2→ CH3OH+H2O + 49.53 KJ/mol

Physical and Chemical Properties

Operation Conditions

Operation temperature: 200 ~ 300℃

Operation pressure: 12 ~ 32Mpa

Space velocity: 5000 ~ 20000h^-1

Space-time yield of methanol: initial≥ 1.0g/(mL•h) end ≥ 0.8g/(mL•h)

Product Advantages

Good activity at low temperature, good thermal stability and good selectivity;

Resistance to high pressure and space velocity;

High space-time yield of methanol;

High strength: uneasy to pulverization.
