High Brightness Advertising Outdoor LED Screen Display FM-B PH6
FM-B PH6 Customized Outdoor Waterproof High Brightness LED Display Screen
Detailed product introduction document:
Applicable scenarios:
1. commercial real estate , stage performance
2. welcome display and restaurant
3. stage performance
4. radio and television studios
5. Floor and Ceiling Display and Media Advertising
6. Interior Decoration
Features:
1. high permeability, high refresh and high gray scale
2. Arbitrary customization: can be customized into square, triangle, circle, cylinder (can be curved into arc) and other irregular shapes
3. good heat dissipation
4. ultra high brightness and High definition
5. small led lamp pitch, wide viewing angle, fast assembling
6. Support front and rear maintenance to reduce maintenance costs: the playback screen appears in a suspended style, which will not affect the building's lighting and vision.
Product Details
Models: FM-B PH6
| Pixel Pitch (mm) | 6 | Maximum Power (W/㎡) | 1000-1200W |
| Pixel Density (dot/㎡) | 27777 | Conventional Power (W/㎡) | 400-600W |
| Module Pixel | 32x32 | LED Composition | RGB three in one |
| Module Size | 192x192 | Eliminate Shadows | Equipment |
| Refresh Rate (HZ) | 1920/3840 | Input Voltage | AC100～240V 50/60HZ |
| Scan Mode | 1/8 Scan | Module Input Voltage | DC4.7～5V±0.2V |
| Lamp Type | SMD2727/SMD3535 | Module Thickness(mm) | 15.6 |
| Brightness (cd/㎡) | 4500-7500 | Cabinet Size | Customized |
| Lifespan (hours) | ≥100,000H | Gray Scale | 14bit |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | Magnetic installation / Cabinet installation |
Application:
