Bench Drilling Machine Servo Motor M3-M16 Touch Screen Electric Tapping Machine
Servo Motor M3-M16 Touch Screen Electric Tapping Machine
1, the machine adopts servo drive control, with intelligent torque protection, instead of the traditional lathe, drilling machine or manual tapping limitations.
2, advanced mechanical design, a variety of processes using mold castings, the overall rigidity is strong, durable, non deformation, beautiful appearance.
3. The high definition touch screen is simple and flexible. It can realize the vertical and horizontal work of complex and heavy workpiece, locate quickly, and process accurately.
4, stepless speed change, manual, automatic, linkage three modes of work, whatever you choose.
5, automatic mode can effectively control the depth of tapping, without the operation button, automatic control by depth controller.
6, repeated positioning fast, tapping speed, high production efficiency.
<MACHINE PARAMETERS>
| M3-M16 Vertical electric tapping machine | M3-M16 universal electric tapping machine | ||
| Brand | WADJAY | Brand | WADJAY |
| Model | M3-M16 | Model | M3-M16 |
| Voltage | 220v,AC,50/60HZ | Voltage | 220v,AC,50/60HZ |
| Power | 600w | Power | 600w |
| Tapping range | M3-M16 | Tapping range | M3-M16 |
| Tapping Collet(8pcs) | 3/4/5/6-8/10/12/14/16 | Tapping Collet(8pcs) | 3/4/5/6-8/10/12/14/16 |
| Tapping Direction | Vertical or horizontal | Tapping Direction | Universal |
| Working radius | 1100mm/1300mm/1900mm | Working radius | 1100mm/1300mm/1900mm |
| Max Speed | 312rpm | Max Speed | 312rpm |
| Customize | Yes | Customize | Yes |
| Weight | 32kg | Weight | 32kg |
| M6-M36 Vertical electric tapping machine | M6-M36 universal electric tapping machine | ||
| Brand | WADJAY | Brand | WADJAY |
| Model | M6-M36 | Model | M6-M36 |
| Voltage | 220v,AC,50/60HZ | Voltage | 220v,AC,50/60HZ |
| Power | 1200w | Power | 1200w |
| Tapping range | M6-M36 | Tapping range | M6-M36 |
| Tapping Collet(11pcs) | 6-36 | Tapping Collet(11pcs) | 6-36 |
| Tapping Direction | Vertical or horizontal | Tapping Direction | Universal |
| Working radius | 1100mm/1300mm/1900mm | Working radius | 1100mm/1300mm/1900mm |
| Max Speed | 150rpm | Max Speed | 150rpm |
| Customize | Yes | Customize | Yes |
| Weight | 72kg | Weight | 72kg |
< STANDARD ACCESSORIES >
