Desktop Mini Laser Engraving Cutting Machine WDL-400A For Jewellery

Price Negotiable
Price: Negotiable
MOQ: 1 set
Delivery Time: 15 working days
Brand: wadley
Product Description





Desktop Mini Laser Engraving Cutting Machine WDL-400A For Jewellery






Product advantages:



1. Our machine's fiber laser source adopt the Germany IPG or China's top quality Raycus famous brand, other key optic parts we adopt the famous brand wo ensure the machine with exporting standard ( A top quality ) .



2. We can customized the laser marking machine as per customer's requirements, for example to design the special fixtures, the automation system and the corresponding matching services.



3. Have the professional QC team for machine quality controal, we need at least 3 days to test the machine's stability before machine shipping out



4. Recommend the machine as per customer's exact needs with the concept of Economic and practical.



5. We not only provide the machine itself, but also provide the professional laser solutions at customer end.



6. After sale team response customer's problems within 12 hours for oversea market, So buy our laser machines without any future worries .



Applications industries :



This kinds of desktop small size fiber laser marking has advantage of high beam quality and high reliability. It is suitable for processing fields that need high marking depth, smoothness and accuracy. It is widely used in: advertising industry, arts industry, electronic components industry, medical device industry, glasses watch and clock industry, IC card industry, plastic tool industry, kitchen and bathroom appliance, etc..



Applicable materials:



It suits to mark on metal and some nonmetal materials, such as: Copper, brass, gold, silver, stainless steel, brass, copper, carbon steel, aluminum, alloy, gold, silver, plastic, rubber, wood, paper, PVC, PU, Epoxy, ABS, etc.








Model No. WDL-400A
Type Portable
Computer Not includes PC
IPG Series: Pulsed, High Energy Ytterbium Fiber Lasers
Nominal average output power 10W - 30W For PEDB-400A /400B /400C; 10W - 50W For PEDB-400D
Central emission wavelength: 1060-1070 nm ,Q-switched operation Output power adjustment range 10%-100%
Emission Bandwidth (FWHM) <10 nm
Pulse width, (FWHM) 100 ns
Pulse Repetition Rate* kHz 20-80 kHz
Energy per pulse (PRR = 20 kHz) 0.95 mJ
Typical beam quality, M2 <1.8
Output fiber delivery length 3m
Operating voltage: 220V
Scanning Speed: 0-7000mm/s
Marking Speed: 0-5000mm/s
Marking size: 110mm×110mm (F-theta 160)
Spot size: ≤ 40 micron (F-theta 160)
Cooling unit: Air cooled
Pilot laser: 650nm diode laser, visible red light for marking guide
Continuous working time: ≥16h
Net Dimensions: 70*20*50cm
Net Weight: 44 kgs
Gross Weight: 60 kgs









Q1. How to send my enquiry?
You can contact us by email, phone call, message (Whats APP, We Chat, Skype).


Q2. How long can I get feedback after enquiry?
We will reply you within 3 hours in working day.


Q3. Delivery time
Machines order takes 30 days after deposit payment received. Please inquiry sales.


Q4. What is the package? Is it suitable for shipment?
Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong for oversea transportation.


Q5. Payment term
30% T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss the details. Welcome to inquiry sales.


Q6.Can I trust you?
Sure, we're Made in China Gold Suppliers,


Q7. How long is the warranty for machines?
Machines warranty is 12 months after receive goods. in Warranty time,we can provide new free parts for changing.


Q8. Can you engineer come to our place to help with machine installation & commission?
Yes, our engineers are available to travel to your place. Round flight tickets & accommodation will be at your cost.
