Manual Horizontal Milling Machine X6132 With Bed Type Working Table
Manual Horizontal Milling Machine X6132 With Bed Type Working Table
The X6132 universal milling machine consists of a bed, a cantilever and a tool holder, a table, a slide and a lifting table. It is widely used in industrial manufacturing.
The Universal Rotary-head Knee-type milling machine X6132 is widely used in the machining workshop, with optional accessories as vertical milling head,dividing head, rotary table, machine vice, milling chuck, etc.
| Specifications | Units | X6132 | X6132B | X6132BH |
| Table size | mm | 320×1325 | 320×1600 | 320×1600 |
| Max. longitudinal of table travel(manual/automatic) | mm | 700/680 | 900/680 | 900/880 |
| Max. transverse travel of table (manual/automatic) | mm | 255/240 | 255/240 | 255/240 |
| Max. vertical travel of table (manual/automatic) | mm | 320/300 | 320/300 | 410/390 |
| Max rotary angle of table | ±45° | ±45° | ±45° | |
| Distance between spindle axis and column guide way | mm | 30-350 | 30-350 | 30-440 |
| Spindle speed step | 18 | 18steps | 18 | |
| Spindle speed range | r.m.p | 30-1500 | 30-1500 | 30-1500 |
| Feed range of table travel | 18 | 18steps | 18 | |
| Main motor power | kw | 7.5 | 7.5 | 7.5 |
| Rapid motor power | kw | 2.2 | 2.2 | 2.2 |
| Overall dimension | mm | 2294×1770×1610 | 2294×2050×1610 | 2294×2050×1790 |
| N.W./G.W. | kg | 2650/2950 | 2740/3040 | 2940/3240 |
The main performance characteristics:
1. Using rectangular guide machine is Rigid good,
2. Work table and guide rail through the ultra audio spark quenching.
3. Work bench X. Y.Z are gear drive automatic feed and manual operation
Application:
1. Universal lifting platform milling machine is a kind of general metal cutting machine tool.
2. Spindle taper hole of the machine can be directly or through the attachment installed all cylindrical milling cutter, disc cutter, molding cutter, end milling cutter tool, suitable for processing a variety of small parts of plane, inclined plane, grooves, holes, and other gear. Is a mechanical manufacturing, mold, equipment, instruments, automobiles, motorcycles and other industries of the ideal processing equipment.
