Stainless Steel R32 Heat Pump Control Home Appliance Air Water Monoblok



Model			YK-02/BPKTR2	YK-03/BPKTR2	YK-04/BPKTR2	YK-05/BPKTR2
Power Supply		V/Ph/Hz	220~240/50-60/1	220~240/50-60/1	220~240/50-60/1	220~240/50-60/1
Heating Condition-Ambient temperature(DB/WB):7/6℃,Water temperature(In/Out):30/35℃
Heating Capacity Range		kW	4.1~9.2	5.4~12.2	6.8~15.2	8.2~18.2
Heating power Input Range		kW	0.85~2.21	1.11~2.92	1.39~3.60	1.69~4.36
COP		W/W	4.15~4.82	4.18~4.85	4.22~4.90	4.18~4.86
Heating Condition-Ambient temperature(DB/WB):7/6℃,Water temperature(In/Out):47/55℃
Heating Capacity Range		kW	3.9~8.7	5.2~11.5	6.5~14.3	7.8~17.1
Heating power Input Range		kW	1.13~3.01	1.50~3.97	1.87~4.96	2.26~5.97
COP		W/W	2.86~3.45	2.87~3.46	2.88~3.48	2.86~3.45
DHW Condition-Ambient temperature(DB/WB):7/6℃,Water temperature(Start/End):15/55℃
Heating Capacity Range		kW	3.8~8.6	5.1~11.3	6.4~14.1	7.6~16.8
Heating power Input Range		kW	0.863~2.30	1.15~3.00	1.44~3.73	1.72~4.48
COP		W/W	3.73~4.4	3.76~4.43	3.78~4.45	3.75~4.42
Cooling Condition-Ambient temperature(DB/WB):35/24℃,Water temperature(In/Out):12/7℃
Cooling Capacity Range		kW	3.08~6.7	4.05~8.8	5.57~12.1	6.08~13.2
Cooling power Input Range		kW	0.905~2.39	1.19~3.16	1.64~4.32	1.79~4.75
EER		W/W	2.8~3.4	2.78~3.38	2.8~3.4	2.78~3.39
Max. Power Input		kW	3.7	4.8	5.7	6.8
Max. Current Input		A	16.5	21	25	30
SCOP Level (35°C)			A+++	A+++	A+++	A+++
SCOP Level (55°C)			A++	A++	A++	A++
Working Ambient Temperature		℃	﹣25~43	﹣25~43	﹣25~43	﹣25~43
Operating Water Temperature		℃	7~70	7~70	7~70	7~70
Refrigerant			R290	R290	R290	R290





Are you looking for a versatile heating and cooling solution that goes beyond the ordinary air conditioner? Look no further than our YK-02/BPKTR2 Series, a cutting-edge frequency conversion heating and Cooling Heat Pump designed to cater to all your comfort needs.Cooling and Heating: This innovative Heat Pump system provides both cooling and heating capabilities for your living space, ensuring year-round comfort. Say goodbye to the hassle of switching between different appliances with this all-in-one solution.Hot Water Service: But that's not all! The YK-02/BPKTR2 Series also offers hot water services, making it a truly multifunctional device. You can enjoy warm showers and hot water whenever you need it, all from a single unit.



Multiple Applications: Our heat pump is designed to excel in various applications, including Air Source Heat Pump, Cooling Heat Pump, DC Inverter Heat Pump, Heat Pump, Pool Heat Pump, and Water Source Heat Pump. It's a versatile workhorse, ready to meet your diverse lifestyle needs.Low Noise, Low Temperature: Are you in need of a heating and cooling solution that operates quietly and efficiently, even in low-temperature environments? Look no further. The YK-02/BPKTR2 Series is your ideal choice, providing a peaceful atmosphere while keeping you comfortable. Plus, it's an eco-friendly option, helping you reduce your energy consumption and carbon footprint.Upgrade your home or workspace with our YK-02/BPKTR2 Series and experience the convenience of a single unit that does it all. Say hello to comfort, efficiency, and environmental consciousness like never before.
