Woven Flexible Black Oxide Cable Mesh , High Tensile SS Cable Mesh
Black Oxide Woven Flexible Stainless Steel Cable Wire Fencing Rope Mesh
High Tensile Balck Oxidized stainless steel wire rope mesh, inter-woven type in particular, is usually used in animal or bird cages, which is also called zoo mesh. The mesh has strong tensile strength and high flexibility, high transparence and wide span. The flexible s.s. cable mesh has unreplacable advantages compared with other mesh products in many aspects like practicability, security, aesthetic property and durability etc.
Black Oxide Mesh Specification
| Material | Cable Diameter | Hole Size | Normal Break |
| SS304/316/316L | 3/32" (2.4MM) | 2.5" x 2.5" | 920 LBS |
| SS304/316/316L | 3/32" (2.4MM) | 2" x 2" | 920 LBS |
| SS304/316/316L | 5/64" (2.0MM) | 2.5" x 2.5" | 676 LBS |
| SS304/316/316L | 5/64" (2.0MM) | 2" x 2" | 676 LBS |
| SS304/316/316L | 1/8" (3.2MM) | 2" x 2" | 1600 LBS |
| SS304/316/316L | 1/8" (3.2MM) | 3" x 3" | 1600 LBS |
Flexible stainless steel cable mesh is the charateristic leading product of Chant Metal Wire Mesh company which has been manufacturing the product since 2007. The independent developed quipments and skilled technique can ensure high quality products and sound service worldwide.
Our normal mesh specification is : cable dia.1mm-4mm and mesh size: 20mm-160mm. Apart from the normal specifications, we can customize other specifications of mesh in different cable diameters and mesh sizes.
Black Oxide Wire Rope Mesh Details
| Mesh Type | Ferruled or Knotted |
| Mesh Angle | 60 degree in rhombus shape |
| Mesh Orientation | Horizontal or Vertical |
| Panle Measurement | Custom-made in width and lenght |
| Finished | Black Oxide |
| Application | Balustrade , Facade Cladding , Animal Enclosure , Aviary Netting |
Installation
Our certification
