China DIN 1025-3 Stainless Steel Profiles Wide I Beams With Parallel Surfaces HEA100-HEA1000 for sale

DIN 1025-3 Stainless Steel Profiles Wide I Beams With Parallel Surfaces HEA100-HEA1000

Price Negotiable

Price: US$1980-US$2180

MOQ: 2 ton

Delivery Time: 10-15 working days after receiveing advance payment

Brand: PUXIANG, TSINGSHAN

Product Description

DIN 1025-3 Wide I-Beams with Parallel Surfaces, HEA100 - HEA1000

H-beams are shaped like an H. H-beam is a structural beam made of rolled steel. It is incredibly strong. It gets its name because it looks like a capital H over its cross section.The H-beam is often a lot heavier than the I-beam, which means it can take more force.H-beams can be used for spans up to 330 feet. H-beams have top and bottom flanges that stick out further from the web than the flanges on I-beams.


Item	Geometry					Weight
Item	h (mm)	b (mm)	tw(mm)	tf (mm)	r1(mm)	(kg/m)
HEA 100	96	100	5	8	12	16.7
HEA 120	114	120	5	8	12	19.9
HEA 140	133	140	5.5	8.5	12	24.7
HEA 160	152	160	6	9	15	30.4
HEA 180	171	180	6	9.5	15	35.5
HEA 200	190	200	6.5	10	18	42.3
HEA 220	210	220	7	11	18	50.5
HEA 240	230	240	7.5	12	21	60.3
HEA 260	250	260	7.5	12.5	24	68.2
HEA 280	270	280	8	13	24	76.3
HEA 300	290	300	8.5	14	27	88.3
HEA 320	310	300	9	15.5	27	97.7
HEA 340	330	300	9.5	16.5	27	104.8
HEA 360	350	300	10	17.5	27	112.1
HEA 400	390	300	11	19	27	124.8
HEA 450	440	300	11.5	21	27	139.7
HEA 500	490	300	12	23	27	155
HEA 550	540	300	12.5	24	27	166.3
HEA 600	590	300	13	25	27	177.8
HEA 650	640	300	13.5	26	27	189.7
HEA 700	690	300	14.5	27	27	204.5
HEA 800	790	300	15	28	30	224.4
HEA 900	890	300	16	30	30	251.6
HEA 1000	990	300	16.5	31	30	272.2
