1500 Kg 1.5t 3000mm 3m 3.5m Lightweight Electric Pallet Stacker Load Small Tonnage Forklift

Price Negotiable
Price: $2000-$3000/unit
MOQ: 1unit
Delivery Time: 15 working days
Brand: KAD
Product Description
Product Description

1500 Kg 1.5t 3000mm 3m 3.5m Lightweight Electric pallet stacker load small tonnage forklift

The Lightweight Electric Pallet Stacker boasts several compelling advantages. Firstly, its lightweight design allows for easy maneuverability and handling, significantly reducing operator fatigue. Secondly, its electric motor ensures quiet and emission-free operation, making it ideal for indoor use and environmentally conscious workplaces. The battery-powered system offers long-lasting runtime and quick recharging, ensuring uninterrupted productivity. Furthermore, its compact size enables it to fit into tight spaces, increasing storage and workspace efficiency. The stacker's user-friendly controls and ergonomic design enhance operator comfort and productivity.

Main Features

1. Medium intensity material handling, stacking and loading/unloading.

2. Designed for narrow aisles .

3. Only suitable for single-sided pallet use.

4. High-strength vertical gearbox improves transmission efficiency, reduces transmission noise, and has a long working life.

5. Folding pedals provide a comfortable working environment for operation.

6. Large-capacity battery ensures long time use.



Specification
Model

CDD1030
CDD1530
Load Capacity
kg
1000
1500
Lifting Height
mm
3000
3000
Load Center
mm
500
500
Fork size
mm
1100*170*50
1100*170*50
Minimum Ground Clearance
mm
30
30
Pedal Length
mm
410
410
Handler Height
mm
1490
1490
Outer Distance between Forks
mm
685
685
Inner Distance between Forks
mm
345
345
Tyre Type

Polyurethane
Polyurethane
Control Way

Handler
Handler
Speed Regulation Way

Stepless Speed Regulation
Stepless Speed Regulation
The Min.Turning Radius
mm
1450
1450
Driving Speed with Full Loads
km/h
4
4
Maximum gradient climb with full load
°
3°/5°
3°/5°
Battery
V/Ah
24V/80A
24V/80A
Driving Motor
kw
0.75
0.75
Lifting Motor
kw
2.2
2.2
Tyre Size
mm
210/80
210/80
Overall dimensions(L*W*H)
mm
1880*860*2100
1880*860*2100
Weight
kg
580
600
Reference Working Time
h
3
3
lncreased height each tonnage


mm
1600/2000/2500/3000/3500
Max height
2100/1600/1850/2100/2350



Features of lightweight electric pallet stackers



The structure of electric pallet stacker is relatively simple and flexible in maneuvering. It is suitable for operation in narrow passages and limited space, and is an important vehicle equipment for warehouses, supermarkets, loading, unloading and stacking palletized goods.
1. energy efficient: the use of electric power drive, not only can improve work efficiency, but also can save energy.
2. Flexible: the equipment is compact and can move freely in a narrow space, and has good steering ability.
3. Simple operation: the control system is simple and easy to understand, the operator only needs to carry out simple instructions to realize the control of the equipment.
4. Safe and reliable: adopting hydraulic system, it can ensure the goods lifting and placing smoothly, and has the function of preventing accidents.
