Z5000 H5000 Series ZONCN Inverter IP65 Water Proof Frequency Inverter VFD VSD
Price:
Negotiable
MOQ:
1 PC
Delivery Time:
7-30 days
Brand:
ZONCN
Product Description
ZONCN Z5000 Series IP65 Waterproof Inverter
Product description
| ITEM | Z5000-BF | |
| Input | Rated voltage, Frequency | 1PH/3PH AC 220V 50/60Hz; 3PH AC 380V 50/60 Hz |
| Voltage Range | 220V: 170~240V; 380V: 330V～440V | |
| Output | Voltage Range | 220V: 0~220V ; 380 V: 0～380 V |
| Frequency Range | 0.10～400.0 Hz | |
| Control method | V/F control, Space vector control | |
| Indication | Operating status/Alarm definition, interactive guidance; eg, frequency setting, the output frequency /current, rotating speed, fault and so on. | |
| Control specification | Output Frequency Range | 0.10～400.00 Hz. |
| Frequency Setting Resolution | Digital input: 0.01 Hz. | |
| Analog input:0,1% of maximum output frequency | ||
| Output Frequency Accuracy | 0.01 Hz. | |
| V/F Control | Setting V/F curve to satisfy various load requirements | |
| Torque Control | Auto increase: auto raise torque by loading condition; Manual increase: enable to set 0.0~20% of raising torque | |
| Multifunctional Input Terminal | 4 multi-function input terminals, realizing functions including 15 section speed control, program running, 4 section acceleration/deceleration speed switch, UP/DOWN function and emergency stop and other functions | |
| Multifunctional Output Terminal | 1 multi-function output terminals for displaying of running, zero speed, counter, external abnormity, program operation and other information and warnings | |
| Acceleration/deceleration Time Setting | 0~999.9 s acceleration/deceleration time can be set individually | |
| Other functions | PID Control | Built-in PID control |
| RS485 | Standard RS485 communication function (MODBUS) | |
| Frequency Setting | Analog input 0～10V, 0～20мА, can be selected; Digital input: input using the setting dial of the operation panel or RS 485 or UP/DOWN | |
| Multi-speed | 4 multi-function input terminals,15 section speed can be set | |
| Automatic voltage regulation | Automatic voltage regulation function can be selected | |
| Counter | Built-in 2 group of counters | |
| Protection function | Overload | 150%, 60s (Constant torque); 120%,60s (variable torque) |
| Over Voltage | Over voltage protection can be set | |
| Under Voltage | Under voltage protection can be set | |
| Other Protections | Output short-circuit, over current, and parameter lock and so on. | |
| Environment | Ambient Temperature | –10℃~40℃(non-freezing) |
| Ambient Humidity | Max. 95% (non-condensing) | |
| Altitude | Lower than 1000м. | |
| Vibration | Max. 0.5 g | |
| Structrure | Cooling Mode | Below 3.7 kW no have fan; Above 5.5 kW Forced air cooling |
| Protective Structure | Below 3.7kw IP 65, 3.7kw and above IP54 | |
Specification
| Model | Input voltage | Rated Output Power (KW) | Rated Input current (A) | Rated Output Current (A) | Motor Power (kW) |
| Z5200A00D7K-BF | 1PH AC220V ±15% | 0.75 | 7.2 | 5 | 0.75 |
| Z5200A01D5K-BF | 1.5 | 10 | 7 | 1.5 | |
| Z5200A02D2K-BF | 2.2 | 16 | 11 | 2.2 | |
| Z5400A0D75K-BF | 3PH AC380V ±15% | 0.75 | 3.8 | 2.5 | 0.75 |
| Z5400A1D5K-BF | 1.5 | 5 | 3.7 | 1.5 | |
| Z5400A02D2K-BF | 2.2 | 5.8 | 5 | 2.2 | |
| Z5400A03D7K-BF | 3.7 | 10 | 9 | 3.7 | |
| Z5400A05D5K-BF | 5.5 | 15 | 13 | 5.5 | |
| Z5400A07D5K-BF | 7.5 | 20 | 17 | 7.5 | |
| Z5400A0011K-BF | 11 | 26 | 25 | 11 | |
| Z5400A0015K-BF | 15 | 35 | 32 | 15 | |
| Z5400A0018K-BF | 18.5 | 38 | 37 | 18.5 | |
| Z5400A0022K-BF | 22 | 46 | 45 | 22 | |
| Z5400A0030K-BF | 30 | 62 | 60 | 30 | |
| Z5400A0037K-BF | 37 | 76 | 75 | 37 | |
| … | … | … | … | … | |
| Z5400A00160K-BF | 160 | 160 |
Packing&Shipping
Company Introduction
Wuhu Zoncn Automation Equipment Co., Ltd is one of leading manufacturers focus on producing inverter and servo products. Our headquarters is in Shanghai, we have factory both in Shanghai and Wuhu with annual sales quantity of 1,000,000 pcs. ZONCN has 6 mains series of VFDs: NZ100, NZ200, Z2000, Z8000, T9000, H5000 (IP65/54), etc. Which can meet various application requirements. And all the products have CE certification.
ZONCN inverters are widely used in textile, print, CNC machine, food package, injection machine, fan, pump, air compressor, water treatment, industrial washing machine and many industrial applications. What’s more, ZONCN is a leading supplier in the fields of air compressor, automatic door, construction machinery, hoisting machinery etc.
Power range: 0.75kw~160kw
Voltage: 1PH/3PH 220v/380v
