Industrial FeiChun REEL-TRADE 12/20kV 4x240mm²+(2x120mm²) High-Tension Strength Cable
Industrial FeiChun REEL-TRADE 12/20kV 4x240mm²+(2x120mm²) High-Tension Strength Cable
Powering large-scale industrial operations requires cables designed for high-tension strength, durability, and reliable performance under extreme conditions.
The FeiChun REEL-TRADE 12/20kV Cable is specifically engineered to meet these challenges, providing robust power transmission for demanding applications such as mobile industrial equipment, ports, and heavy-duty reeling systems.
This cable combines 4x240mm² power conductors with 2x120mm² support cores, offering exceptional flexibility, tensile strength, and performance in dynamic and high-stress environments.
Applications of FeiChun REEL-TRADE Cable
The REEL-TRADE 12/20kV Cable is designed to meet the demands of:
Key Features of FeiChun REEL-TRADE Cable
The REEL-TRADE Cable integrates cutting-edge materials and advanced manufacturing techniques to ensure top-tier performance in harsh environments.
| Feature | Details |
|---|---|
| Voltage Rating | 12/20kV |
| Power Conductors | 4x240mm² tinned copper |
| Support Cores | 2x120mm² tinned copper |
| Insulation Material | Cross-linked polyethylene (XLPE) |
| Inner Sheath | Halogen-free thermoplastic material |
| Outer Sheath | High-grade polyurethane (PUR), abrasion and chemical resistant |
| Temperature Range | -40°C to +90°C |
| Bending Radius | 6x Ø (fixed installation), 12x Ø (dynamic operations) |
| UV Resistance | Superior protection against prolonged exposure to sunlight |
| Flame Retardant Properties | Complies with IEC 60332-1 |
| Tensile Strength | Enhanced with reinforced support cores for reeling and pulling applications |
| Chemical Resistance | Resists oils, solvents, and corrosive agents |
Advantages of FeiChun REEL-TRADE Cable
1. Exceptional High-Tension Strength
The reinforced support cores provide excellent resistance to mechanical stresses during reeling, ensuring that the cable withstands tension in high-speed operations without deformation or performance loss.
2. Optimized for Dynamic Use
Designed for reeling systems, this cable ensures consistent performance in applications involving repetitive motion and extreme mechanical demands.
3. Enhanced Durability
With its polyurethane outer sheath, the cable offers superior resistance to abrasion, chemical exposure, and UV radiation, making it ideal for outdoor and heavy-duty environments.
4. Reliable Power Transmission
The 4x240mm² tinned copper conductors ensure stable and efficient power delivery, while the 2x120mm² support cores reinforce the cable structure to prevent damage during reeling and high-tension use.
5. Eco-Friendly and Safe
The halogen-free construction minimizes toxic emissions in the event of a fire, protecting personnel and the environment.
Technical Specifications
Below is a summary of the technical data for the FeiChun REEL-TRADE Cable:
| Parameter | Specification |
|---|---|
| Voltage Rating | 12/20kV |
| Power Conductors | 4x240mm² |
| Support Cores | 2x120mm² |
| Insulation Material | XLPE |
| Outer Sheath Material | Polyurethane (PUR), chemical and abrasion-resistant |
| Temperature Range | -40°C to +90°C |
| Bending Radius | 6x Ø (fixed), 12x Ø (dynamic) |
| Flame Retardant Standard | IEC 60332-1 |
| Tensile Strength | Reinforced to handle high tension |
Problems Solved by FeiChun REEL-TRADE Cable
The REEL-TRADE Cable addresses several common challenges faced by industries relying on high-tension cables:
| Problem | Solution |
|---|---|
| Mechanical Failure Under Tension | Reinforced support cores prevent structural damage during high-tension use. |
| Abrasion in Harsh Environments | Durable polyurethane sheath resists wear and tear, extending cable lifespan. |
| Electrical Losses Over Long Runs | High-quality copper conductors ensure efficient power transmission. |
| Chemical and Oil Exposure | Outer sheath resists oils, chemicals, and solvents commonly found in industrial environments. |
| UV Degradation in Outdoor Use | UV-resistant design ensures long-lasting performance in exposed conditions. |
Installation and Maintenance Best Practices
To maximize the lifespan and performance of the FeiChun REEL-TRADE Cable, adhere to the following guidelines:
| Aspect | Best Practice |
|---|---|
| Handling | Use proper handling equipment to prevent damage during transport and installation. |
| Bending Radius | Maintain the specified bending radius to avoid undue stress on the cable. |
| Alignment in Reeling | Ensure the cable is correctly aligned to prevent twisting or kinking during operation. |
| Inspection | Conduct periodic checks for wear, abrasion, or damage to the outer sheath. |
| Cleaning | Clean with non-corrosive agents to remove debris or contaminants. |
Material and Manufacturing Advantages
The FeiChun REEL-TRADE Cable stands out due to its superior materials and advanced manufacturing processes:
Real-World Applications
1. Port Operations
In port terminals, this cable powers high-capacity cranes and mobile machinery, ensuring uninterrupted operations despite harsh environmental conditions.
2. Heavy Industrial Equipment
The REEL-TRADE Cable is ideal for industrial equipment that requires frequent movement, such as reeling systems, ensuring reliable power and mechanical stability.
3. Mining Operations
In mining environments, where tension and abrasion are constant concerns, this cable provides durable and efficient power delivery for mobile machinery.
Why Choose FeiChun REEL-TRADE Cable?
Unmatched Durability: Withstands extreme conditions, from UV exposure to abrasion and tension.
Optimized Performance: Designed for dynamic applications with high mechanical stresses.
Eco-Friendly Design: Halogen-free construction prioritizes safety and environmental compliance.
Proven Reliability: Engineered to deliver consistent performance in critical industrial operations.
The Industrial FeiChun REEL-TRADE 12/20kV 4x240mm²+(2x120mm²) High-Tension Strength Cable is a powerful solution for industries requiring durable and reliable power transmission under demanding conditions.
Whether you’re working in ports, mining, or heavy industry, this cable ensures safety, efficiency, and long-term performance.
Contact FeiChun Cables today to learn more about how the REEL-TRADE Cable can enhance your operations and reduce downtime!
Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
