Feichun SPREADER REEL PUR-HF Advanced Low Voltage D12YST11YU11Y-JZ Cable for High-Performance Vertical Reeling Operations
Feichun SPREADER REEL PUR-HF: Advanced Low Voltage D12YST11YU11Y-JZ Cable for High-Performance Vertical Reeling Operations
The Feichun SPREADER REEL PUR-HF (Type: D12YST11YU11Y-JZ) is a cutting-edge solution for demanding vertical reeling applications. This cable stands out with its exceptional mechanical and electrical performance, making it the go-to choice for industries requiring reliability, flexibility, and durability in their systems.
Designed with advanced materials and engineering, it ensures optimal performance even in high-stress environments, while maintaining compliance with safety and environmental standards.
Product Overview
Core Application Domains
The Feichun SPREADER REEL PUR-HF excels in:
- Vertical reeling systems: Ideal for cranes, elevators, and other high-lift equipment.
- High mechanical stress environments: Withstands intense forces and continuous movement.
- Industrial automation: Ensures reliable power and signal transmission.
- Material handling equipment: Perfect for applications like forklifts and conveyors.
- Offshore and marine installations: Resistant to saltwater and harsh marine conditions.
Key Design Differentiators
- Exceptional Flexibility: Its unique design handles extreme mechanical stress with ease.
- Halogen-Free Construction: Enhances safety and reduces environmental impact.
- Advanced Material Technology: The polyurethane sheath offers unmatched protection from abrasion, oils, and weathering.
Technical Specifications
Electrical Characteristics
The Feichun SPREADER REEL PUR-HF is designed to deliver reliable electrical performance:
| Parameter | Specification |
|---|---|
| Rated Voltage | 0.6/1 kV (600/1000V) |
| Maximum Operating Voltage | AC: 0.7/1.2 kV, DC: 0.9/1.8 kV |
| AC Test Voltage | 4 kV (5 Minutes) |
Conductor Composition
| Feature | Details |
|---|---|
| Material | Plain copper |
| Flexibility Classification | Class 5 (DIN EN 60228) |
| Core Identification | White with black numerical marking |
| Core Arrangement | Central aramid strain element, layered twisting |
Mechanical Robustness
| Feature | Specification |
|---|---|
| Maximum Torsional Stress | ±50°/m |
| Minimum Bending Radius | 6 x Cable Diameter |
| Maximum Travel Speed | Up to 180 m/min |
Environmental and Performance Compliance
Fire Safety
| Standard | Compliance |
|---|---|
| Fire Performance | IEC 60332-1 |
| Halogen-Free Compounds | Yes |
Operational Environment
| Condition | Temperature Range |
|---|---|
| Fixed Installation | -50°C to +80°C |
| Flexible Operation | -40°C to +80°C |
| Conductor Temperature Limits | Continuous: 90°C, Short Circuit: 250°C |
Additional Environmental Resistances
| Resistance | Test Standard |
|---|---|
| Oil Resistance | EN 60811-404 |
| Water Resistance | Suitable for permanent underwater use (up to 50m) |
Critical Performance Considerations
Available Configurations
| Configuration | Details |
|---|---|
| Core Counts | 24x2.5, 30x2.5, 36x2.5, 42x2.5 |
| Specialized Configurations | 9x(5x2.5), 14x(4x2.5) |
| Conductor Diameter | 2 mm across all ranges |
Load and Stress Management
| Feature | Details |
|---|---|
| Enhanced Tensile Support | Central aramid strain element for higher load capacity |
| Torsion Protection | Reinforced open braid design |
| Outer Sheath | Black polyurethane with flame-retardant properties |
Comparative Advantages
The Feichun SPREADER REEL PUR-HF offers unparalleled benefits:
- Superior Flexibility: Withstands extreme mechanical and torsional stress.
- Comprehensive Environmental Resistance: Functions in oil, water, and harsh weather conditions.
- Advanced Safety Features: Flame-retardant, halogen-free, and compliant with fire safety standards.
- Precision Engineering: Optimized for high-performance vertical reeling systems.
Recommended Deployment Considerations
Installation Best Practices
To ensure optimal performance:
- Follow the minimum bending radius specifications.
- Use kellum grips for proper tensile load management.
- Confirm compatibility with your mechanical systems.
Potential Limitations
Before deployment:
- Verify the application requirements with the manufacturer.
- Ensure the cable meets your temperature and environmental conditions.
Standards and Certification References
The Feichun SPREADER REEL PUR-HF complies with:
- DIN EN 60228
- DIN VDE 0295
- IEC 60332-1
- EN 60811-404
Conclusion
The Feichun SPREADER REEL PUR-HF is more than a cable; it’s a game-changer for industries requiring robust solutions for vertical reeling operations. Its exceptional design, safety features, and environmental adaptability make it the ideal choice for high-stress applications.
Technical Support and Consultation
For detailed installation guidance, system compatibility checks, or custom configuration requests, contact Feichun Technical Support. We’re here to provide tailored solutions for your needs.
Note: Specifications are based on the latest technical data. Always refer to official datasheets for the most up-to-date information.
Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
