Feichun (N)SSHOEU PUR 0.6/1kV Cable For Flexible Use And Fixed Installation Open-Cast Mining Applications, In Quarries, On Construction Sites And Similar Applications, With Heavy Mechanical Stresses
Feichun (N)SSHOEU PUR 0.6/1kV Cable For Flexible Use And Fixed Installation Open-Cast Mining Applications, In Quarries, On Construction Sites And Similar Applications, With Heavy Mechanical Stresses
When it comes to powering operations in tough environments, the Feichun (N)SSHOEU PUR 0.6/1kV cable stands as a reliable and robust solution. Designed to endure heavy mechanical stresses, this cable excels in open-cast mining, quarries, construction sites, and other challenging conditions.
With exceptional abrasion resistance and unmatched durability, it is engineered to handle the demands of flexible use and fixed installations alike. From industrial to agricultural applications, and even underwater operations, this cable proves its versatility time and again.
Key Features of Feichun (N)SSHOEU PUR Cable
Durable Material Composition
- Conductor: Made from finely stranded, tinned copper (class 5), ensuring excellent conductivity and flexibility.
- Core Insulation: Utilizes EPR rubber (3GI3), known for its thermal stability and electrical insulation properties.
- Outer Sheath: A robust Polyurethane (PUR) layer offers superior abrasion resistance and withstands exposure to oils, UV, and seawater.
Electrical Performance
- Rated Voltage: 0.6/1kV with a test voltage of 3.5kV.
- Short Circuit Tolerance: Operates safely under temperatures as high as 250°C during short circuits.
Environmental Resistance
- Flame Retardant: Compliant with EN/IEC 60332-1-2.
- Halogen-Free: Enhances safety by reducing toxic emissions during a fire.
- Oil and Ozone Resistant: Perfect for industrial and outdoor use.
- Water Resistance: Operates at depths of up to 10 meters in wastewater, rainwater, and other non-aggressive water types.
Applications and Use Cases
Open-Cast Mining and Quarries
The cable's robust design ensures it can handle heavy mechanical stresses typical in mining operations, delivering consistent power even under harsh conditions.
Construction Sites
Its abrasion resistance and UV stability make it ideal for outdoor environments, ensuring reliability in high-wear scenarios.
Industrial and Agricultural Settings
Feichun (N)SSHOEU PUR cables excel in explosion-hazard areas, industrial setups, and agricultural operations, adapting seamlessly to a variety of challenges.
Water Applications
The cable operates efficiently in wastewater, cooling water, and seawater (to limited extents), making it suitable for marine and underwater installations.
Technical Specifications
| Parameter | Details |
|---|---|
| Conductor Sizes | 3x2.5 mm² to 4x185 mm² |
| Cable Diameter (Min) | 10.4 mm |
| Cable Diameter (Max) | 54.7 mm |
| Test Voltage | 3.5 kV |
| Temperature Range (Fixed) | -40°C to +80°C |
| Flame Retardant Compliance | EN/IEC 60332-1-2 |
| Water Depth (Max) | 10 meters |
| Permanent Tensile Strength | 15 N/mm² |
| Torsional Stress | ±50°/m |
Challenges in Real-World Applications
Water Resistance
Operating in aggressive water requires careful pre-testing to ensure the cable’s material properties can withstand the conditions.
Mechanical Stresses
The PUR sheath ensures long-term protection against abrasion, but proper handling during installation is crucial to prevent damage.
Temperature Extremes
Designed to function seamlessly between -40°C and 80°C, the cable delivers consistent performance without thermal degradation.
Compliance with Standards
Feichun (N)SSHOEU PUR cables meet or exceed the following standards:
- DIN VDE 0250-812: Ensures cable durability and structural integrity.
- EN/IEC 60332-1-2: Verifies flame retardancy.
- DIN VDE 0298-4: Specifies installation guidelines for bending and tension limits.
Advantages Over Traditional Rubber Cables
- Abrasion Resistance: PUR outperforms rubber in handling wear and tear.
- Flexibility: Suitable for both fixed and dynamic installations.
- Environmental Resilience: Better resistance to oils, chemicals, and UV exposure.
![]()
Practical Tips for Installation and Maintenance
Practical Tips for Installation and Maintenance
Installation Guidelines
- Follow VDE 0298-3 specifications for bending radius:
- Fixed Installations: 4x cable diameter.
- Flexible Installations: 5x cable diameter.
Maintenance Checks
- Regularly inspect for mechanical wear or damage, especially in high-stress environments.
Water Environment Considerations
- Ensure that cables in wastewater or chemically aggressive environments are accessible for periodic inspection and maintenance.
Conclusion
The Feichun (N)SSHOEU PUR 0.6/1kV cable is a reliable and durable choice for heavy-duty applications. Its superior abrasion resistance, compliance with international standards, and versatility make it an essential component for challenging environments.
From mining operations to construction sites and underwater applications, this cable delivers exceptional performance.
