1. Introduction
Overview of Feichun FMSGSGO VG95218T63 Halogen-Free Light Power Cables
When it comes to marine electrical systems, safety, durability, and reliability are paramount. Feichun FMSGSGO VG95218T63 halogen-free light power cables are designed to meet the rigorous demands of shipboard installations.
These cables are manufactured to the highest standards, ensuring reliable operation in harsh marine environments.
Significance in Marine Applications
Marine vessels operate in environments characterized by saltwater exposure, extreme temperatures, and constant vibration.
Feichun FMSGSGO VG95218T63 cables offer halogen-free construction, fire resistance, and superior durability, making them indispensable for ensuring safe and efficient operations on ships.
Compliance with VG 95218 Part 63 Standards
The Feichun FMSGSGO VG95218T63 is compliant with the VG 95218 Part 63 standard, ensuring it meets stringent military and maritime requirements. It also adheres to Bureau Veritas (BV) 3400 guidelines for installation, guaranteeing a high level of safety and performance.
Scope of Application
These cables are ideal for fixed installations on ships, suitable for all locations, including open decks exposed to environmental stressors.
2. Technical Specifications and Standards Compliance
2.1 Core Construction
Copper Conductor Specifications
The core conductor is made of plain, round stranded copper, compliant with VG 95218 Part 63.
Stranding Benefits:
Flexibility: Stranded conductors allow easy routing, even in tight spaces.
Corrosion Resistance: The high-quality copper withstands salt spray and moisture exposure.
Insulation Material
The cores are insulated with cross-linked LS0H (Low Smoke Zero Halogen) material.
Advantages:
Fire Safety: Emits minimal smoke during a fire, aiding in evacuation.
Environmental Compliance: Free from toxic halogens, reducing the risk of corrosion to nearby equipment.
Screen Construction and Braiding
Screen Type: Braided screen of bare copper.
Purpose:
Protects against electromagnetic interference (EMI).
Ensures signal integrity and reduces the risk of cross-talk.
Outer Sheath
The outer sheath is made of crosslinked polymer, offering exceptional protection.
- Durability: Resistant to abrasion, chemicals, and UV radiation.
- Flexibility: Maintains performance under extreme conditions.
2.2 Electrical Characteristics
| Parameter | Value |
|---|---|
| Nominal Voltage (U) | 250 V |
| Test Voltage | 2 kV |
| Max Conductor Temp | 90°C |
| Short Circuit Temp | 250°C |
These characteristics ensure reliable power delivery in dynamic marine environments.
2.3 Thermal Properties
| Thermal Property | Value |
|---|---|
| Ambient Temperature (Fixed) | -30°C to 90°C |
| Laying Temperature (Min) | -15°C |
| Short Circuit Temperature Limit | 250°C |
The wide temperature range ensures performance stability in both polar and tropical climates.
3. Safety and Environmental Compliance
3.1 Fire Performance
- Flame Retardancy: Complies with EN/IEC 60332-1-2 and EN/IEC 60332-1-24, minimizing fire spread risks.
- Low Smoke: Tested under IEC/EN 61034-2, ensuring low smoke density for improved visibility during fire emergencies.
- Halogen-Free: Certified to IEC/EN 60754-1/2, reducing toxic gas emissions.
3.2 Chemical Resistance
- Oil Resistance: Certified to IEC/EN 60811-404, ensuring durability against lubricants and fuels.
- Ozone Resistance: Built to withstand prolonged exposure to ozone in marine atmospheres.
4. Installation Guidelines
4.1 Mechanical Properties
| Parameter | Value |
|---|---|
| Permanent Tensile Strength | 50 N/mm² |
| Bending Radius | 5 x OD (Outer Diameter) |
Proper handling ensures longevity and performance.
4.2 Installation Best Practices
Cable Routing Considerations
- Avoid sharp bends and maintain the minimum bending radius.
- Use supports and ties to prevent sagging or movement.
Termination Techniques
- Use appropriate glands to maintain IP rating and prevent moisture ingress.
- Ensure proper earthing of the screen for EMI protection.
Support Spacing
Install supports at intervals to minimize mechanical stress and movement.
5. Common Installation Challenges and Solutions
5.1 Environmental Challenges
| Challenge | Solution |
|---|---|
| Salt Spray Exposure | Use corrosion-resistant materials and seals. |
| Temperature Fluctuations | Select cables rated for a wide temperature range. |
| Vibration | Secure cables using vibration-dampening clamps. |
6. Maintenance and Inspection
6.1 Routine Maintenance
- Visual Inspections: Check for signs of wear, such as abrasions or cracks.
- Insulation Resistance Testing: Verify electrical integrity.
6.2 Troubleshooting Guide
Common Faults:
Loose Connections: Tighten securely.
Abrasion: Replace damaged sections.
7. Regulatory Compliance and Documentation
7.1 Classification Society Requirements
- Ensure compliance with BV 3400 installation regulations.
- Maintain proper documentation, including test certificates.
7.2 Quality Assurance
- All cables undergo stringent testing for compliance with VG 95218-63 and EN/IEC standards.
8. Conclusion
Feichun FMSGSGO VG95218T63 marine cables provide a robust, compliant, and environmentally friendly solution for shipboard installations.
With advanced materials and manufacturing processes, these cables ensure durability, safety, and performance reliability in the most challenging marine environments.
For further inquiries, contact Feichun Cable for expert advice and technical support.
Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
