Feichun Type FM2XCCH-FFR Marine Communication Cable: Technical Guide and Comparative Analysis
Feichun Type FM2XCCH-FFR Marine Communication Cable: Technical Guide and Comparative Analysis
The Feichun Type FM2XCCH-FFR is a high-performance marine-grade cable meticulously designed for signal and communication systems in marine environments.
Built to withstand harsh maritime conditions, this cable ensures optimal transmission of high-frequency signals while providing unmatched electromagnetic interference (EMI) protection.
Its dual-layer screening and robust construction make it ideal for applications where signal integrity and reliability are paramount.
1.2 Key Differentiators from FM2XAH-FFR
| Feature | FM2XCCH-FFR | FM2XAH-FFR |
|---|---|---|
| Screening | Individual pair screen + overall copper braided screen | Overall aluminum screen |
| EMI Protection | Superior (dual-layer screening) | Standard |
| Mechanical Protection | Enhanced separation layers | Basic protection |
| Applications | High-interference environments | General signal applications |
2. Technical Specifications and Comparative Analysis
2.1 Construction Features
Shared Features with FM2XAH-FFR
- Conductor: Electrolytic, stranded, annealed copper wire (IEC 60228 Class 2)
- Fire Barrier: Mica tape for fire resistance
- Insulation: Cross-linked polyethylene (XLPE)
- Outer Sheath: Halogen-free, flame-retardant, UV-resistant polyolefin compound (SHF 1)
Enhanced Features Unique to FM2XCCH-FFR
Dual-Layer Screening:
Individual aluminum tape screens with drain wires for each pair
Overall copper braided screen with 90% minimum coverage
Separator Layers:
Separator tape over individual pairs
Enhanced inner covering with separating foil
2.2 Performance Parameters
| Parameter | Specification |
|---|---|
| Operating Temperature | -40°C to +90°C |
| Minimum Installation Temp | -15°C |
| Rated Voltage | 150/250V |
| Test Voltage | 1.5 kV |
| Bending Radius (Fixed) | 6 × Overall Diameter |
3. Applications and Advantages
3.1 Primary Applications
- Critical Communication Systems: Ideal for radio, radar, and information systems on marine vessels.
- High-Frequency Signal Transmission: Ensures signal integrity in noisy environments.
- Radar Systems: Supports operations in high EMI conditions with superior protection.
3.2 Advantages Over FM2XAH-FFR
| Aspect | Advantage |
|---|---|
| EMI Protection | Superior interference rejection and cross-talk prevention due to dual-layer screens. |
| Signal Integrity | Enhanced signal attenuation and frequency stability in challenging environments. |
| Mechanical Durability | Improved separation layers for structural integrity and protection. |
4. Installation Guidelines
4.1 Special Installation Considerations
Screen Termination
- Ensure proper grounding of individual pair screens and overall screen to maximize EMI protection.
Handling and Flexibility
- Consider the cable’s increased weight and slightly reduced flexibility due to enhanced screening.
4.2 Installation Challenges and Solutions
| Challenge | Solution |
|---|---|
| Screen Termination | Plan structured termination to handle dual-layer screening. |
| Weight and Routing | Use cable trays with proper support to manage additional weight. |
| Bend Radius Compliance | Adhere to the 6× diameter rule to prevent damage to the screening layers. |
5. Maintenance and Testing
5.1 Routine Maintenance
- Screen Continuity Testing: Verify integrity of both individual pair screens and the overall screen.
- Insulation Resistance: Regular testing to ensure performance.
- Visual Inspections: Check for outer sheath damage or wear.
5.2 Performance Verification
| Test | Purpose |
|---|---|
| Cross-Talk Measurement | Verify separation and isolation. |
| Signal Attenuation | Ensure minimal signal loss. |
| EMI Rejection | Confirm effective shielding. |
6. Compliance and Standards
| Standard | Description |
|---|---|
| IEC 60092/376 | Construction guidelines for marine cables. |
| IEC 60331 | Fire resistance standards for electrical cables. |
| IEC 60754 | Halogen content testing to ensure low-smoke, non-toxic emissions. |
| IEC 61034 | Smoke density measurements for improved safety visibility during fires. |
7. Selection Guidelines
7.1 When to Choose FM2XCCH-FFR over FM2XAH-FFR
- High-EMI Environments: For areas with heavy interference, such as engine rooms or radar installations.
- Signal Integrity Priority: When minimal signal degradation and superior cross-talk isolation are needed.
7.2 Environmental Considerations
| Condition | Recommendation |
|---|---|
| Temperature Extremes | Use in environments ranging from -40°C to +90°C. |
| UV Exposure | Suitable for outdoor installations due to UV-resistant sheath. |
| Complex Routing | Plan for additional weight and dual-layer screening during installation. |
8. References and Standards
- IEC 60228: Conductors of insulated cables.
- IEC 60092/376: Electrical installations in ships.
- EN 50289: Test methods for communication cables.
- IEC 61034: Measurement of smoke density of cables.
Summary Table: FM2XCCH-FFR vs. FM2XAH-FFR
| Feature | FM2XCCH-FFR | FM2XAH-FFR |
|---|---|---|
| Screening | Dual-layer (individual + overall screen) | Single-layer (overall screen) |
| EMI Rejection | Superior | Standard |
| Flexibility | Slightly reduced | Higher flexibility |
| Weight | Heavier due to braided screen | Lighter |
By choosing Feichun Type FM2XCCH-FFR, customers can ensure superior performance and reliability in demanding marine communication applications.
Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
