Lights Control Grand Ma2 Grand Ma2 Console Dmx Controller Ma2 Lighting Console
Lights Control Grand Ma2 Grand Ma2 Console Dmx Controller Ma2 Lighting Console
[Specification]
Real-time control for up to 65,536 parameters per session in connection with NPU (equivalent to 256 DMX universes)
4,096 parameters
6 DMX outputs
6 x DMX outputs + 1 x DMX input
2 x internal TFT wide mode touchscreens (15.4" WXGA)
1 x internal command screen (9" SVGA)
15 x motorized executor faders
2 x motorized A/B fader (100mm)
Integrated keyboard drawer
6 x encoders
1 x trackball
1 x wheel
2 x Ethernet
4 x USB2.0
MIDI in/out support
LTC/SMPTE support
Art-Net support
RDM support
Dimension: 986* 650*218
Net weight: 52kg
[Parameter]
| • Intel Core i5 6500CPU, 8G memory, SSD Kingston 120g, Gigabyte GTX1030 alone |
| • 1 9-inch touch screen |
| • Two 15.4-inch electric lifting widescreen touch screens. |
| • Display window fixed mouse cannot be dragged |
| • Support physical buttons to close the window and run other lighting software |
| • X1-X20 User1 and User2 button LEDs on the 9-inch screen can be illuminated in synchronization with the program |
| • Support Art-net network expansion to 256 domains, all signals can be output without NPU |
| • 1 external HDMI display |
| • Input voltage: 110V ~ 220V 50 ~ 60Hz, built-in high-power UPS uninterruptible power supply |
| • Built-in 6 DMX-512 output interfaces, 1 DMX-512 input interface, the maximum expansion can be 256DMX output port. |
| • A highly sensitive trackball |
| • Built-in keyboard drawer |
| • 1 LTC time code input interface, 1 MIDI time code input interface. |
| • 1 master dimming wheel, 4 attribute encoding wheels, 1 master fader, 2 AB faders |
| • 15 program playback faders, 50 program storage function keys |
| • 4 USB interfaces, 1 audio interface, 1 network interface, 2 work light interfaces |
| • Gross weight:76KG |
| • Flight case package:102*33*73CM |
