400W LED Beam Spot Wash 3in1 Moving Head Light with Cmy Light

【Features】

Zoom angle: 4-35 degrees Wash angle:10-50 degrees High-speed
Strobe: 0-30 times/sec. Adjustable speed strobe effect. Strobe macro functio

Color: 8 colors + open. Color half-color function
Color mixing system: linear CMY+CTO color mixing system
Fixed gobos: 12 fixed patterns + open
Rotating gobos: 7 glass patterns, each glass pattern can be independently forward and reverse
Prism system: standard single 3-facet prism and 8 prism, each prism can be independently forward and reverse
Macro function: console reset function, self-propelled mode, master-slave mode

【Specification】

Input voltage: AC110V-240V/50-60HZ
Power consumption: 430W
Light source specification: Imported new LED Module engine 400W
Light source life: 50000 hours
Lumen illuminance: 5 meters 100,000 lm
Color temperature: 8000K CRI>85 OPTICS

Dimming system: 0-100% linear adjustment
Focusing system: linear adjustment from 4 meters to 50 meters
Frost: 1 independent frost filter, soft and natural light spot
Channel mode: 23 channels
Display mode: LCD display, key + touch dual operation mode
Control signal: International standard DMX512. With RDM function, online software upgrade is available, dial address code

Pan: 540 degrees (16bit precision scan) electronic error correction
Tilt: 270 degrees (16bit precision scanning) electronic error correction
Cooling method: Adopt axial fan to enhance cooling
Safety device: with electronic temperature control overheating protection,electronic temperature control automatic power-off protection when the overheating system fails
Appearance material: high temperature resistant plastic
Working environment: -20 degrees - 40 degrees

Protection level: IP20

Net weight: 22.5KG

Product size: 38*27*65CM (L*W*H)

【Product Description】

7 glass gobos
each glass gobo can be customized and rotation

【Packing list】

• 1 × LED BSW moving head
• 2 × Omega bracket or Folding clamp
• (the default is Omega bracket,please contact us if need the folding clamp)
• 1 × Power cable
• 1 × DMX cable
• 1 × Safety rope
• 1 × User manual
•
• 【My show time】

1, After confirming the product with the customer, prepare the materials2,Solder circuit board
3,Color wheel,gobo wheel,prism wheel and frost wheel
4,Assemble parts
5,Aging test before shipping
6,Waterproof test
7,Packaging and labeling( Flightcase can be customized your own LOGO)
8,Loading and delivery



1.Packing method (the default package is carton,please contact us if need the flightcase)

2.Shipping Method: By Air, sea, or Express(DHL, UPS, FedEx, etc) as request.

3.Payment Methods: T/T, Paypal, Western Union, MoneyGram,Credit Card,Cash
