2000w Industrial Electric Motors Permanent Magnet DC Motor Industrial Fan

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: 30days

Brand: ABC

Product Description

1000w 1500w 2000w Permanent Magnet Synchronous Motor DC Motor Industrial Fan

Product parameter:

Model No.	Phase	Rated voltage (V)	Rated power (W)	Rated torque (N.m)	Rated speed (RPM)	Speed range (RPM)
BL190200-01	3 Phases	AC 380 50/60Hz	1050	9	1450±50	220-1450
BL190205-02	3 Phases	AC 380 50/60Hz	750	10	580±20	220-580
BL190215-01	3 Phases	AC 380 50/60Hz	1100	13	630±20	220-660
BL190230-01	3 Phases	AC 380 50/60Hz	1500	15.84	700±20	220-720
BL190250-01	3 Phases	AC 380 50/60Hz	2200	22.00	750±20	220-780
BL190190-01	3 Phases	AC 380 50/60Hz	370	2.7	960±20	220-1060
BL190190-01B-01	3 Phases	AC 380 50/60Hz	550	2.2	1000±20	220-1060
BL190190-02	3 Phases	AC 380 50/60Hz	1050	9	780±20	220-780

Product Features:

Comparison items	Permanent magnet EC motor fan	AC asynchronous motor fan
Compared Quantity	1 pc	1 pc
Size	14601460580 mm	14601460580 mm
Maximum air flow	39000 m³/h	39000 m³/h
Speed	560 r/min	560 r/min
Input power	0.75 kW/h	1.0 kW/h
Starting current	0.3A~1.9A soft start, stable start, small current impact, no impact on the power grid.	1.5A~2.5A does not start smoothly, and the current impact is large, which is a big impact on the transformer and the power grid.
Annual electricity consumption of one fan (24H/day, 365days/year)	10.7524*365=6570 KWH	1124*365=8760 KWH

Picture Display:

Q1: Are you a factory
A1: Of course.

Q2.Do you have certificate?
A2:Our company has achieved ISO9001, CE certification.

Q3: How about the delivery time?
A3: Our production period is normally 10-20 days after receiving advance payment. For some standard model, we can delivery
immediately if we have goods in stock.

Q4: Can we print the LOGO on products?
A4: Yes, OEM is available with the permission of our customers.

Q5: What is your payment term?
A5: T/T or L/C, if you want other payment terms, please contact us.
