Transparent Rigid Sunpower Bifacial Solar Panels 100w 120w 150w 160w 180w Ce Rohs
Transparent Rigid Sunpower Solar Panel 100w 120w 150w 160w 180w Ce Rohs Emc Lvd Solar Tree Smartflower Use Bificial Sola
More power output per square meter,ideal for RV,boat roof or home when space is limit.Smaller size save space.
-Premium Aesthetics
Without copper ribbon on front and using high aesthestics solar cells,either black or silver frame fits your
roof,boat,stand alone solar systems better.
-Excellent weak light performance and Maximum energy per watt
Deliver the most energy in demanding real world conditions,in partial shade,weak light,and hot temperatures.
-Durability-Leading quality raw material
SunPower back contact cell is the only cell built on a solid copper foundation.Virtually impervious to the corrosion
and cracking that degrade conventional panels.Low iron tempered glass,high density aluminium frame,top
brand EVA and backsheet,our panel produces 9% more power than others year by year.
-5 years quality insured,free replacement,maintenance
- 10 years power output more than 90%
-25 years power output more than 80%
| Model No. | eRigid M120w |
| Product Name | bificial rigid sunpower solar panel 100w 115w 120w 150w 160w 180w customize all sizes ce rohs emc lvd for solar tree smartflower |
| Maximum Power[Wp] | 120 |
| Solar Cell | Back Contact Cell |
| Cell Array[Pcs] | 4*8 |
| Cell Efficiency | 24.4% |
| Size[mm] | 540*1050*30 |
| Max Power Voltage Vmp[V] | 19.6 |
| Max Power Current Imp[A] | 6.12 |
| Open Circuit Voltage Voc[V] | 23.13 |
| Short Circuit Current Isc[A] | 6.49 |
| Net.Weight[kg] | 6.2 |
| Power tolerance[%] | ±3% |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.44 |
| Temperature Coefficient Voc[[%/K] | -0.33 |
| Temperature Coefficient Isc[[%/K] | 0.06 |
| Maximum System Voltage[V] | 1000 V |
