JMZ-TK-8A Rubber Shock Absorber For Stable And Accurate Missile Launches In Defense
JMZ-TK Series
JMZ-TK series vibration isolator is one of the star products of Xi'an Hoan Microwave Co., Ltd. As a high-tech enterprise focusing on the R&D, production and sales of vibration damping technology, Xi'an Hoan Microwave Co., Ltd. has been committed to providing customers with high-quality, efficient and reliable vibration reduction solutions. As the company's flagship product, JMZ-TK series vibration isolator equipment not only inherits the company's technical genes, but also performs well in practical applications, and has won the recognition and trust of our customers.
Today, the JMZ-TK series friction dampers are the preferred object of many professional fields. In the field of defense, it is widely used in the electronic equipment of command centers, the launch system of strategic missiles, and the on-board precision instruments of various armored vehicles. In the strong impact force and violent vibration environment at the moment of missile launch, JMZ series friction dampers can effectively cushion and ensure the stability and accuracy of the launch system. When the armored vehicle is driving at high speed on rough terrain, it can absorb bump vibrations, so that the communication, navigation and other electronic equipment in the vehicle can operate normally, providing a solid guarantee for the smooth development of operations.
The wide application of JMZ-TK series friction dampers benefits from its advanced friction damping technology and continuous innovation design concept. The R&D team has conducted in-depth research on the vibration characteristics and use environment of various types of equipment, and continuously optimized the product performance to meet the growing demand for vibration reduction in different industries. In the future, JMZ-TK series friction dampers will continue to expand their application territory, emerge in more emerging fields, continue to contribute to the stable development of various industries around the world, and write a brilliant chapter in the field of vibration damping.
| Model | Installation dimensions(mm) |
Dimensions (mm) |
|||||||
| B | M | d | A | C | Ø1 | Ø2 | H1 | H2 | |
| JMZ-TK-2.5A～8A | 46 | 6 | 4.1 | 58 | 20 | 55 | 22 | 36 | 3.6 |
| JMZ-TK1-25/40/50 | 63 | 12 | 8.2 | 78 | 20 | 70 | 22 | 56 | 6 |
Technical data sheet
| Model |
Nominal load (N)
|
Load range |
Natural frequency ≤(Hz) |
Loading working height H0±1(mm) |
Limit displacement(mm) | Impact resistance test |
Single weight ≤(g) |
Service life | ||
| Vertical | standard | |||||||||
| above | under | |||||||||
| δ1 | δ2 | δ3 | ||||||||
| JMZ-TK-2.5A | 25 | 20～30 | 33 | 42 | 4 | 4 | 4 | 100g | 380 | 10 |
| JMZ-TK-4A | 40 | 30～50 | ||||||||
| JMZ-TK-5A | 50 | 40～60 | ||||||||
| JMZ-TK-6A | 60 | 50～70 | ||||||||
| JMZ-TK-7A | 70 | 60～80 | ||||||||
| JMZ-TK-8A | 80 | 70～90 | ||||||||
| JMZ-TK1-25 | 250 | 200～300 | 20 | 70 | 7 | 8 | 7 | 60g | 1100 | |
| JMZ-TK1-40 | 400 | 300～480 | ||||||||
| JMZ-TK1-50 | 500 | 400～600 | ||||||||
FAQ
1.Q:Are you a manufacturer or a trading company?
2.Q:Can you customize products for us?
A:Yes, we have the capability to customize our products to meet your specific needs. Please contact us with your requirements, and our team will work with you to create a tailored solution that fits your preferences.
3.Q:What is the lead time?
A:Sample will usually take 2 to 5 days.For the mass production,it will estimated take 7 to 20 day, Faster delivery when our
factory has stock.
4.Q:Can I get some samples before place order and how long for a sample?
A:Yes, sample order is accepted
5.Q:How is your shipping?
A:1)worldwide shipping service available
2)please contact before order as shipping cost varies time to time.
6.Q:Do you offer discounts for bulk orders?
A:Yes, we offer discounts for bulk orders. The discount percentage may vary depending on the order quantity.
