Prefabricated Vibration Isolators JZP-1.0B For Vibration Isolation And Noise Reduction
JZP-B Series
In today's era of vigorous development of industry and construction, the operation of various machinery and equipment, the bearing of building structures and the operation of transportation facilities inevitably produce vibration and noise. The Assembled Vibration Isolator (JZP) is like a silent guardian, quietly playing a key role behind the scenes, creating a more stable, quiet and comfortable environment.
On railway tracks, JZP plays a vital role. As the speed of trains continues to increase and the volume of trains continues to increase, the problems of track vibration and noise are becoming more and more prominent. The application of prefabricated vibration isolators can significantly reduce the vibration of the track, and reduce the interference of train operation to the surrounding buildings, residents' lives and facilities along the railway. This will not only help improve the environmental performance of rail transport, but also create a more comfortable travel experience for passengers and promote the sustainable development of rail transport.
From industrial production to daily life, from urban construction to transportation, the prefabricated vibration isolator (JZP) silently "absorbs shock and noise" for our world with its excellent vibration isolation and noise reduction performance. It is a shining pearl in modern engineering technology, constantly pushing various industries to move towards more efficient, stable, comfortable and safe direction, so that we can enjoy the convenience brought by scientific and technological progress, but also free from vibration and noise, and embrace a quiet and harmonious living and working environment.
Dimensional parameter table
| Model | D | H | h | A | B | d1 | MG | R |
| JZP | 58 | 29 | 17 | 50 | 60 | 5.5 | M6 | 5 |
| JZP-B | 46 | 30 | 18 | 40 | 50 | 5.5 | M6 | 5 |
| JZP-C | 36 | 20 | 13.5 | 32 | 40 | 4.3 | M5 | 4 |
Technical data sheet
| Model |
Nominal load (kg) |
Static displacement (mm) |
Operating temperature (℃) |
Resonant frequency (Hz) |
Damping ratio | Impact test | expiration date | Expiration date |
| JZP-1.0B | 1.0 | ≤0.3 | -45～+65 | 41.5±5 | ≥0.13 | 100g12次 | 8 | 5 |
| JZP-1.5B | 1.5 | |||||||
| JZP-2.0B | 2.0 | |||||||
| JZP-3.0B | 3.0 | |||||||
| JZP-4.0B | 4.0 | |||||||
| JZP-4.5B | 4.5 | |||||||
| JZP-5.0B | 5.0 |
* Unique Characteristics of Xi'an Hoan's Vibration Isolators *
* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays
