Corrosion Resistant Prefab Metal Warehouse Building Galvanized
Corrosion-Resistant Long- Time Used Prefabricated Steel Warehouse
1.Product Description
Light steel structure building is a new type of building structure system, which is formed by the main steel framework linking up H-section, Z-section, and U-section steel components, roof and walls using a variety of panels and other components such as windows and doors. Light steel structure building is widely used in warehouses, workshops, large factories, and so on.
2.Advantages of Steel Structure Building
| Environmental protection | The steel structure warehouse built with light steel structure can also play a role in environmental protection, because the cost of water and soil resources is far lower than that of traditional cement warehouse, and in this kind of buildings, building materials are the most environmentally friendly color steel building materials on the market, so it plays a very good protection role for the environment. |
| Steel structure is more popular than ever | For the whole building group, this kind of building materials is undoubtedly the most popular mainstream building materials in today's society. |
| Anti-corrosion insulation effect | Its thermal insulation effect is very significant, put things in it do not have to worry about any problems, so for the steel structure warehouse to strengthen the protection of the main body of the light steel structure will not cause any problems because of the temperature difference outside, so that it has achieved the role of corrosion insulation, prolong its service life. |
3. Product Specifiactions
| Main Patrs | Item Parts | Specifications |
| Main Steel Frame | steel beam | Q355B welded H type steel |
| steel column | Q355B welede H type steel | |
| Bracing Parts | brace | Q235B,Q345B round steel hot-dip galvanizing |
| roof purlin | C or Z kind steel galvanizing | |
| wall purlin | C or Z kind steel galvanizing | |
| roof | EPS sandwich panel, fiber-galss sandwich panel, rock wall sandwich panel | |
| wall | EPS sandwich panel, fiber-glass sandwich panel, rock wall sandwich panel | |
| Accessories | bolts | Ordinary bolts, anchor bolts, expansion bolts,baslet bolts |
| gutter | Galvanized steel plate,stainless steel | |
| windows | alumium alloy glass window,aluminum alloy shutter window | |
| doors | sliding or rolling window | |
| downpipe | PVC pipe,PUC pipe | |
| edge cover | Color steel sheet,thickness is 0.5mm |
4.Company
5.steel structure building
The characteristics and advantages of steel structures should include high strength and light self-weight. This is very important because they are much lighter than concrete and can reduce the cost of the foundation. Then it has good seismic performance and high ductility, which is an advantage in earthquake-prone areas. The construction speed is fast, with factory prefabrication and on-site assembly, and the construction period is short. It has a large spatial span and is suitable for large venues, such as stadiums and aircraft hangars. The materials are also recyclable, in line with the trend of green buildings.
6. Quotation
|
||||||||||
| Type of Building | ||||||||||
| Please state type of building, ie: workshop, warehouse, hall, hangar, farm, roof structure or other construction | ||||||||||
| Dimension | Length | Width | Wall Height | Total Height | ||||||
| Construction Site | ||||||||||
| Roofing and Walls | (1)sandwich panel (2)profile steel sheets (3)steel sheet+glasswool blanket (4) no walls-only roof with structures | |||||||||
| Contact Name | ||||||||||
| Company Name | ||||||||||
| Phone Number | ||||||||||
| Additional info | ||||||||||
| Send us sketches, drawings or the project, if you have | ||||||||||
