7.8Ah 10000lux Corded Led Miner Head Lamp Underground Mining Cap Lamp
Main Features for Model GL8-C mining headlamp:
1. Brightness: 10000lux high beam corded lamp.
2. One main light and two auxiliary lights.
3. 7.8Ah big battery capacity and 16hours lighting working time.
4. Low power warning function for safety lighting.
5. Silicon button cap with good touch and long life usage.
6. Special material with flame resistant, impact resistant.
7. Environmental: Lithium battery with short circuit protection, over charging protection and over discharging, free maintenance long battery life span.
8. OEM and ODM available. Write the request to cap lamps, such as clients company name, LOGO, series No and user name.
9. Optical Design: According to LED Luminous Flux, Light cup curve and current to design the Light Beam.
10. ATEX explosion-proof, Dust-proof, waterproof, flame resistant, shock resistant.
Technique Data Sheet
|
Model No.
|
GL8-C
|
|
Light source
|
one main light two auxiliary lights
|
|
Battery Capacity
|
7.8Ah rechargeable li-ion battery
|
|
Rated Voltage
|
3.7V
|
|
Main light current
|
450mA
|
|
Power of main light
|
1.67W
|
|
Illuminous
|
216um
|
|
Brightness
|
10000lux
|
|
Life span of main light
|
100000hrs
|
|
Battery cycles
|
1000 cycles
|
|
Working time
|
18hrs
|
|
Weight
|
420g
|
|
Water-proof grade
|
IP68
|
