1200-4000 mm Plastic Machine Line For PE Double Wall Corrugated Pipe Production
Price:
120000-400000 ＄
MOQ:
1 set
Delivery Time:
70-90 days
Brand:
Huashida
Product Description
Plastic Machine for PE Double Wall Corrugated Pipe
Basic Info.
Automation
Automatic
Computerized
Computerized
Customized
Customized
Condition
New
Pipe Diameter
110-800mm
Extruder
Single Screw Extruder
Electrical Elements
ABB Inverter, Simens PLC and Contactors
Pipe Structure
Corrugated Double Layer
Technology
High Speed Closed-Type Water Cooling Technology
Transport Package
Standard Package
Specification
ISO9001: 2008
Trademark
HSD
Origin
Qingdao
HS Code
8477209000
Production Capacity
50 Units/Year
Product Description
HDPE Double Wall Corrugated Pipe Production Line
![Plastic Machine for PE Double Wall Corrugated Pipe]()
We supply the double wall corrugated pipe extrusion lines with the pipe of diameter from 110mm up to 1200m
Equipment list
1. Effective single screw extruder 2 sets
2. Effective vacuum feeder and dry hopper
3. High speed corrugated pipe forming machine
4. Vacuum machine
5. Effective spray cooling tank
6. Automatic planetary cutting machine
7. Automatic stacker
8. Pipe puncher
9. Pipe package machine
10. 2-position coiler(single wall 90-160mm)
![Plastic Machine for PE Double Wall Corrugated Pipe]()
Pipe extrusion according to requirements of:
ASTM_D790-2003, GBT2918-1998, ISO_1133-2005, GB3682-2000,
BS EN ISO 1133-2005,CJT 225-2011,GBT_19472.1-2004,NEN-EN 13476-1
Unique design adopted by mold running system, the compact structure ensure the corrugated pipe forming machine running smoothly, so the equipment has a longer service life.
New structure of circulating water tubing system avoid the inertial impact happened in present machines with old design.
The tubing system connected with the mold block adopts "slip-on connection" and "Plane sealing ring", it is much easier to change different sizes. You are not required to remove any tubes,
so it will save your much of time.
We supply the double wall corrugated pipe extrusion lines with the pipe of diameter from 110mm up to 1200m
Equipment list
1. Effective single screw extruder 2 sets
2. Effective vacuum feeder and dry hopper
3. High speed corrugated pipe forming machine
4. Vacuum machine
5. Effective spray cooling tank
6. Automatic planetary cutting machine
7. Automatic stacker
8. Pipe puncher
9. Pipe package machine
10. 2-position coiler(single wall 90-160mm)
| Pipe diameter (ID. mm) |
110 | 160 | 200 | 225 | 300 | 400 | 500 | 600 | 800 |
| SN8 (kg/m) |
0.9 | 1.7 | 2.1 | 2.8 | 5.1 | 8.0 | 12.5 | 18.5 | 31 |
| SN4 (kg/m) |
0.75 | 1.5 | 1.8 | 2.5 | 4.2 | 6.0 | 10.0 | 13.5 | 25 |
| Line speed (m/min)/ Capacity (kg/h) |
≥6 | ≥5 | ≥4.2 | ≥3.8 | ≥2.8 | ≥1.9 | ≥1.3 | ≥1.1 | ≥0.8 |
ASTM_D790-2003, GBT2918-1998, ISO_1133-2005, GB3682-2000,
BS EN ISO 1133-2005,CJT 225-2011,GBT_19472.1-2004,NEN-EN 13476-1
Unique design adopted by mold running system, the compact structure ensure the corrugated pipe forming machine running smoothly, so the equipment has a longer service life.
New structure of circulating water tubing system avoid the inertial impact happened in present machines with old design.
The tubing system connected with the mold block adopts "slip-on connection" and "Plane sealing ring", it is much easier to change different sizes. You are not required to remove any tubes,
so it will save your much of time.
