Polyethylene Jacket Casing Pipe SystemFor 110-1680mm Thermal Pre-Insulated Pipe
Product Description
HDPE Jacket Pipe Extrusion Line
The HDPE jacket pipe extrusion line is a high-efficiency, energy-saving solution designed for producing HDPE pipes. These pipes serve as protective covers for PU foam thermal pre-insulated pipes, adhering to international standards.
Key Benefits:
- High Speed: Optimized for rapid production.
- Energy Efficiency: Designed to minimize energy consumption.
- Quality Compliance: Meets international standards for durability and performance.
This extrusion line is ideal for manufacturers looking to enhance their production capabilities for protective pipe applications.
The HDPE jacket pipe is produced by vacuum calibrating method with smooth internal and external wall, long service life, good anti-corrosion insulation and mechanical performance.
| Style | PE-110/500 | PE-655/1380 | PE-960/1860 | PE-1155/2200 |
| Main Extruder | SJ-75/33 | SJ-120/33 | SJ-150/33 | SJ-150/33 |
| Pipe diameter | Φ110-600mm | Φ655-1380mm | Φ960-1860mm | Φ1155-2200mm |
| Capacity | 250-350kg/h | 700-900kg/h | 1000-1200kg/h | 1350kg/h |
| Installed power | 160kw | 480kw | 580kw | 650kw |
| Length | 26m | 36m | 45m | 45m |
Production line composition:
-1set Vacuum loader
-1set Hopper dryer
-1set High-efficiency single screw extruder
-1set Vacuum calibration table
-1set Water spraying tank
-1set Hauling machine
-1set Cutting machine
-1set Discharging Frame
PE-110/500
PE-650/1380
PE-960/1860
HDPE Jacket Pipe Production Line
Our HDPE jacket pipe production line features a compact design and high automation, allowing operation by a single person to reduce labor costs. Built for durability, it includes a high-efficiency extruder for stable performance and high output, producing pipes with smooth, uniform walls while minimizing raw material waste, eliminating edge trimming.
We provide a complete solution, including design, installation, commissioning, and training. With 389 sets of global production experience and a team of 9 senior engineers, we ensure quality support from our expert workstation in China.
Qingdao Huashida Machinery Co., LTD, is a manufacturer of series of plastic pipe machines, municipal pipe machines, pipe insulation&anticorrosion machines, and pipe jointing&anticorrosion materials, with 21 years of production experience.
Our main products are:
1. HDPE jacket pipe for pre-insulated pipe Production Line (110-2000mm)
2. Rigid pre-insulated pipe Production Line
3. Flexible pre-insulated pipe(PERT) production line
4. Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
5. Steel pipe derusting line
6. PE pressure pipe/Water Gas supply pipe production line
6. PP/PE plastic board/sheet/geomembrane production line
7. NBR PVC Thermal insulation tube/plate production line
8.Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun(extruder), PE PP welding rod.
We have been working with more than 400 overseas customers and exporting our products to Kazakhstan, Uzbekistan, Iran, Turkey, Russia, Nigeria and other countries.
