PP Extruder Machine for Solid Wall Water Supply HDPE Pipes with Blue Strip
PP Extruder Machine for Solid Wall Water Supply HDPE Pipes with Blue Strip
This HDPE water gas supply pipe production line features advanced fully automated design, suitable for manufacturing PE80 and PE100 pipes with diameters ranging from 20mm to 2000mm. It is widely used in municipal water supply, agricultural irrigation, and other fields. The production line is equipped with a high-efficiency extruder, precision molds, a water cooling system, a high-speed traction machine, and an intelligent cutting machine, ensuring precise dimensions and smooth surfaces of the pipes. The PLC control system enables fully automated operation and includes online detection functions to guarantee stable product quality. With high production capacity, low energy consumption, and user-friendly operation, the production line complies with environmental standards, making it an ideal choice for producing high-quality HDPE water supply pipes.
| Model | Pipe diameter | Screw | KiloWatt | Output |
| SPEG-110 | 20-110mm | SJ75X33 | 180kw | 350kg/h |
| SPEG-250 | 63-250mm | SJ90X33 | 280kw | 500-1000kg/h |
| SPEG-630 | 315-630mm | SJ120X33 | 522kw | 1000-1200kg/h |
| SPEG-1200 | 710-1200mm | SJ150X33 | 680kw | 1000-1600kg/h |
| SPEG-2200 | 1000-2200mm | SJ150X33 | 1200kw | 2000-2500kg/h |
SPEG-110
SPEG-250
SPEG-630
SPEG-1200
[Feeding&Drying] → [Extrusion Molding] → [Mold Shaping] → [Cooling] → [Traction and Cutting] → [Marking]
Main equipment list
-1set Vacuum loader
-1set Hopper dryer
-1set High-effeciency single screw extruder
-1set 25/25 single screw extruder for mark line
-1set Vacuum calibration table
-2/4 set Water spraying tank
-1set Hauling machine
-1set Cutting machine
-1set Stacker
- Advanced Technology: Incorporates cutting-edge technology for optimal performance.
- Stable Operation: Ensures reliable and consistent performance.
- High Automation: Reduces labor costs through automated processes.
- Quality Assurance: Meets international standards for superior quality.
- Comprehensive Solutions: Offers complete services including design, installation, commissioning, and training.
- Global Experience: Draws on expertise from 389 production sets worldwide.
- Expert Team: Supported by 9 professional senior engineers.
- High-End Facility: Features a state-of-the-art plastic machinery workstation in China.
Our main products are:
1. HDPE jacket pipe for pre-insulated pipe Production Line (110-2000mm)
2. Rigid pre-insulated pipe Production Line
3. Flexible pre-insulated pipe(PERT) production line
4. Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
5. Steel pipe derusting line
6. PE pressure pipe/Water Gas supply pipe production line
6. PP/PE plastic board/sheet/geomembrane production line
7. NBR PVC Thermal insulation tube/plate production line
8.Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun(extruder), PE PP welding rod.
