Euchner NZ2RS-511SVM5 (ORDER NO. 090027) Safety Switch NZ.RS, Roller Plunger, Steel Roller Ø 12 Mm, Plug Connector SVM5
Price:
variable
MOQ:
1
Delivery Time:
Negotiate
Brand:
Euchner
Product Description
Euchner NZ2RS-511SVM5 (ORDER NO. 090027) Safety switch NZ.RS, roller plunger, steel roller ø 12 mm, plug connector SVM5
Specification
|
Electrical connection values
| Rated insulation voltage Ui | 50 V |
| Rated impulse withstand voltage Uimp | 1.5 kV |
| Utilization category | |
| AC-15 | 4 A 30 V |
| DC-13 | 4 A 24 V |
| Short circuit protection according to IEC 60269-1 | 4A gG |
| Switching current | |
| min. at DC 24V | 10 mA |
| thermal rated current Ith | 4 A |
Mechanical values and environment
| Approach speed | 0.1 ... 20 m/min |
| Connection type | |
| 1 x | Plug connector M12 |
| Number of NO contacts | 1 |
| Number of door position positively driven contacts | 1 |
| Actuating element | |
| Slide bearing metal | Roller plunger |
| Actuating force | 15 ... 30 N |
| Installation orientation | any |
| Mechanical life | 30 x 10⁶ |
| Contact bounce time | max. 3 ms |
| Switching principle | Snap-action switching contact |
| Contact closing time | max. 4 ms |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +80 °C |
| Material | |
| Contact | Silver alloy, gold flashed |
| Housing | Anodized die-cast alloy |
Characteristic values according to EN ISO 13849-1 and EN IEC 62061
| B10D | Mission time | |
|---|---|---|
| Sichere Positionserkennung | 2x107 | 20 y |
| Important! Values valid at DC-13 100 mA/24V | ||
