KBZE 301-6663 3016663 CAT G3508 G3512 G3516 G3520 GAS ENGINE SPARK PLUG FITS CUM MINS 2866879 3607738 4090121 QSV81 QSV91
Price:
DIRECTLY FACTORY PRICE
MOQ:
Acceptable Trial Order
Delivery Time:
3-5DAYS AFTER RECEIVED PAYMENT(WORKING DAYS)
Brand:
KBZE
Product Description
Product Description
KBZE 301-6663 3016663 CAT G3508 G3512 G3516 G3520 GAS ENGINE SPARK PLUG FITS CUM MINS 2866879 3607738 4090121 QSV81 QSV91
Product Details
Model NO.
301-6663 243-4291 2866879 3607738 4090121 4098162 4302738 4924504 5373898
Type
SPARK PLUG
Application
CAT EXCAVATOR
Certification
CE, ISO9001: 2000
Condition
New
MOQ
1 Piece
Quality
High-Quality
Part Name
SPARK PLUG
Part Number
301-6663 243-4291 2866879 3607738 4090121 4098162 4302738 4924504 5373898
Transport Package
Standard
Specification
STANDARD
Origin
CHINA
PRODUCT SHOWS:
PRODUCT SKETCH:
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | 0T-0102 | [24] | BOLT (3/8-16X0.625-IN) | |
| 2 | 4P-7483 | [2] | BRACKET | |
| 3 | 4P-7485 | [20] | BRACKET | |
| 4 | 5M-2894 | [24] | WASHER-HARD (10.2X18.5X2.5-MM THK) | |
| 5 | 6V-8927 | [8] | BOLT-SOCKET HEAD (6-32X0.5-IN) | |
| 6 | 418-4862 | [20] | TRANSFORMER GP-IGNITION | |
| 7 | 110-9268 | [20] | CLIP | |
| 8 | 117-6512 | [20] | GROMMET | |
| 9 | 118-3508 | [2] | GROMMET | |
| 10 | 118-3509 | [12] | GROMMET | |
| 11 | 118-2950 | [6] | GROMMET | |
| 12 | 119-0814 | [2] | GASKET | |
| 13 | 143-9607 | [22] | STRAP-CABLE | |
| 14 | 194-8518 | [20] | SPARK PLUG | |
| (EACH INCLUDES) | ||||
| 301-6663 | [1] | SPARK PLUG | ||
| 15 | 150-9576 | [2] | HARNESS AS-WIRING (IGNITION) | |
| (EACH INCLUDES) | ||||
| 1S-9593 | [10] | STRAP-CABLE | ||
| 4P-8367 | [10] | ROD-SUPPORT | ||
| 8T-6342 | TUBE-HEAT SHRINK (3.2-MM DIA)(100-CM) | |||
| 8T-8730 | [20] | SOCKET-CONNECTOR (16-GA TO 18-GA) | ||
| 110-8359 | [1] | CONNECTOR AS (37-PIN) | ||
| 155-2270 | [10] | KIT-CONNECTING PLUG (2-PIN) | ||
| (EACH KIT INCLUDES PLUG AS, WEDGE, & INTERFACE SEAL) | ||||
| 16 | 5B-5059 | [20] | BOLT (7/16-14X5-IN) | |
| 17 | [20] | RETAINER AS | ||
| 18 | 239-0640 | [1] | FILM-WARNING (EXPLOSION HAZARD) | |
| 4P-7369 | [1] | HARNESS AS-WIRING (IGNITION, REPAIR) | ||
| 117-1254 | [1] | HARNESS AS-WIRING (IGNITION, REPAIR) | ||
| (SERVICES ONE CYLINDER) | ||||
| A | NOT PART OF THIS GROUP | |||
| B | USE AS REQUIRED | |||
| C | CHANGE FROM PREVIOUS TYPE | |||
| E | ORDER BY THE CENTIMETER | |||
| F | NOT SHOWN | |||
| J | HARNESS ASSEMBLY MARKED J INCLUDES PARTS MARKED J FOR SERVICE OF ONE CYLINDER | |||
| Y | SEPARATE ILLUSTRATION | |||
FAQ
1)Which brands of machinery you work with?
We supply parts for brands like: Hitachi,Cat,Komatsu,Sumitomo,Hyundai,Kobelco,Liebherr,JCB,etc,We mainly do small to meddium size excavators.
2)Can you send us the price lists(so that we do not always bother you when we need the price information)?
Sorry that we do not have price list.You are welcomed to contact us if you have any interesting products.
3)Payment terms:
Flexible payment,T/T and WESTERN UNION.Your money is safe if we do business.
4)Shipment:
International express(DHL,Fedex,TNT...),Air and marine transportation are available.
As per your time request,considing of Volume and Weight in details,we will suggest you which is best way to shipment.
5)How do you make our business long-term and good relationship?
We keep good quality and competitive price to ensure our customers benefit.We respect every customer as our friend and we sincerely do business and make friends with them.no matter where they come from.
We supply parts for brands like: Hitachi,Cat,Komatsu,Sumitomo,Hyundai,Kobelco,Liebherr,JCB,etc,We mainly do small to meddium size excavators.
2)Can you send us the price lists(so that we do not always bother you when we need the price information)?
Sorry that we do not have price list.You are welcomed to contact us if you have any interesting products.
3)Payment terms:
Flexible payment,T/T and WESTERN UNION.Your money is safe if we do business.
4)Shipment:
International express(DHL,Fedex,TNT...),Air and marine transportation are available.
As per your time request,considing of Volume and Weight in details,we will suggest you which is best way to shipment.
5)How do you make our business long-term and good relationship?
We keep good quality and competitive price to ensure our customers benefit.We respect every customer as our friend and we sincerely do business and make friends with them.no matter where they come from.
