Metal Brazed Heat Exchanger Gasketed Plate And Frame Heat Exchanger
Stainless Steel 304/316 Brazed Refrigerant Plate Heat Exchanger For Chiller
PRODUCT DESCRIPTION
1. Plate heat exchangers are devices used to transfer heat between two fluids through a series of metal plates. These plates are arranged in such a way that they create a large surface area for heat transfer while maintaining a small footprint. The two fluids, which can be liquids or gases, flow through separate channels formed by the plates. Heat is transferred from one fluid to the other through the plates, allowing for efficient heat exchange.
2.Plate heat exchangers are commonly used in HVAC systems, refrigeration, industrial processes, and in the food and beverage industry. They offer advantages such as high heat transfer efficiency, compact size, and the ability to handle high pressures and temperatures. Additionally, they are relatively easy to maintain and can be disassembled for cleaning or maintenance.
3. Plate heat exchangers are versatile and can be designed for various applications depending on the specific heat transfer requirements and operating conditions.
| Model | VH20/VS20 |
| Plate Thickness | 0.5/0.6mm |
| Plate Hole Size | 200mm |
| Maximum Throughput | 680m3/h |
| Adapter Pipe For Large-diameter | DN200 |
| Working Pressure | 1.0/1.6MPa |
| Test Pressure | 1.3/2.1Mpa |
| Model |
Standard maximum flow rate m3/h |
Maximum number of assembled pieces N |
Clamping size A |
Maximum length L1 |
| VH20 | 680 | 275 | N*(3.8+X) | 2651 |
| VS20 | 680 | 251 | N*(4.0+X) | 2351 |
| Product parameter of gasketed plate heat exchanger | |
| Item | plate heat exchanger |
| Brand | Victory |
| Plate material | Titanium/Nickle/hastolly/Stainless steel 0.5mm 0.6mm 0.7mm 0.8mm 1mm |
| Gasket material | NBR HNBR EPDM HEPDM VITON FKM Silicone |
| Frame material | Painted Carbon steel |
| Color of frame | blue or customed color |
| Connection type | flange or thread |
| Flange standard | ANSI ASME BS BA JIS DIN GB ISO |
| Tightening bolt | M24 M30 M39 |
| Design pressure | highest 20mpa, lowest 10Mpa |
| Work pressure | normal 12.5Mpa |
| MOQ | 1 set |
| Package | polywood case |
| Warranty | one year |
| OEM | Can make replacement |
Applications
HVAC Systems: Plate heat exchangers are used in heating, ventilation, and air conditioning systems to transfer heat between the building's air and the circulated water or refrigerant.
Refrigeration: They are utilized in commercial and industrial refrigeration systems for cooling and heat transfer processes.
Food and Beverage Processing: Plate heat exchangers play a crucial role in food and beverage processing for pasteurization, heating, and cooling of liquids such as milk, juice, beer, and wine.
Chemical Processing: They are employed in chemical manufacturing processes for heating and cooling of various chemicals and fluids.
