700W BSWF Profile Moving Head Ellipsoidal Stage Light AC100-240V 50/60Hz
Price:
Negotiable
MOQ:
1 Sets
Delivery Time:
7-15days
Brand:
Bright lighting
Product Description
700W BSWF Led Moving Head Framing Light Spot Light Ellipsoidal Stage Light
Specifications:
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power | 980W |
| Light source: | 700W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6800K |
| Caliber: | 138mm Frontal lens for greater performance |
| Color rendering index | Standard mode Ra>75, high CRI mode Ra>90 |
| Luminous flux: | 28000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 36CHs |
| Display system: | 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 7 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2700K-7000K linear adjustment |
| Prisms: | Rotating 3-faced prism+6-faced linear prism, two prisms can be overlaid |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 8 fixed gobos+open position |
| Rotating gobo Wheel: | 6 gobos (pluggable), outer diameter 27.9mm, effective diameter 16.5mm, thickness 1.1mm+Open position |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90° |
| Frost system: | 0~100% linear atomization |
| Iris system: | 5%~100% smooth adjustment |
| Beam Aperture: | 4.5°~50° fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan | 540° (16 bit precision scanning) |
| Tilt: | 270° (16 bit precision scanning) |
| Pan/Tilt: | Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45 |
| Product size: | 510*345*800(mm) |
| Carton size: | 730*690*590 (mm) |
| Product net weight: | 40KG |
| Product gross weight: | 48.5KG |
| Product appearance: | : flame retardant, high temperature resistance, folding clamp |
Additional details:
How to operate:
1:Power-on test: Before using it for the first time, make sure the product is normal and turn on the power supply for testing.
2:Controller settings: Set the required light effect, color and other parameters through the matching controller.
3:Installation and fixation: According to the needs of the site and scenery requirements, select the appropriate installation method and location, and fix the lamps.
1:Power-on test: Before using it for the first time, make sure the product is normal and turn on the power supply for testing.
2:Controller settings: Set the required light effect, color and other parameters through the matching controller.
3:Installation and fixation: According to the needs of the site and scenery requirements, select the appropriate installation method and location, and fix the lamps.
Application:
1:Film and television shooting: As auxiliary lighting equipment on film and television sets, it can meet the needs of different shooting scenes.
2:Sports events: Used in stadiums or stadiums to provide lighting effects for competitions and recognition sessions, stimulating enthusiasm for athletes and spectators
Service:
Provide after-sales service
display:
