New 220W Bicolor LED TV Studio Video Panel Light Film Studio Stage Lighting Equipment
Matters needing attention:
1:Avoid using in high temperature and high humidity environment for a long time, so as not to affect the life of the lamp.
2:Clean the surface of lamps and cooling fans regularly to ensure smooth heat dissipation.
3:Check the fixed installation before use to ensure that the beam lamp is in a stable state.
Working principle:
1:LED light source: LED light-emitting diodes generate high-brightness color light through current excitation.
2:Beam modulation: The LED light is diffused, focused or projected through the appropriate optical device to form the required beam shape and effect.
3:Color adjustment: By adjusting the brightness and color of the LED light source to achieve a variety of lighting effects, such as monochrome, multi-color mixing, color transformation, etc.
Specifications:
| LED POWER: | 1920pcs * 0.2W |
| LED Color: | 3000K - 6000K |
| Color Rendering Index(CRI): | Ra≥95 |
| LED Life Time: | over 50,000 hours |
| Voltage: | AC100-240V |
| Max.power : | 220W |
| Power Supply Brand: | MEAN WELL |
| Fixed Lens: | 180° |
| LED Life Time: | over 50,000 hours |
| Dimmer: | 10~100% linearly adjustable |
| Dimming Curve: | 4 kinds |
| Dimming Frequency: | 500HZ - 25000HZ optional |
| Light body: | Die casting Aluminum |
| Body color: | Black |
| Touch screen: | LCD with touch screen |
| Control Protocol: | RDM / DMX |
| Control System: | DMX, Auto run and Master/Slave |
| DMX Channels: | 2CH |
| Working Temperature: | -10~40℃ |
| Cooling system: | No noise fan |
| IP Grade: | IP20 |
| Net Weight: | 9.5kgs |
| Gross Weight: | 11.5kgs |
| Packing Size: | 88*46*14.5cm (1pc/carton) |
Display:
