BWG25 X 5/8" SS Steel Strapping Band 0.5x16mm Metal Packing
Steel Strapping Band BWG25 X 5/8" SS Band 0.5x16mm Metal Packing
Steel strapping is the oldest and most commonly used banding materials to this day. Steel strapping is designed for extreme tasks that require a heavy or very heavy-duty strap. Steel strapping is optimal for packaging industrial equipment, heavy construction materials, and shipping steel coils.
Bluing Metal Steel strapping band is the strongest of all strapping materials and should be used with products with sharp, rigid edges, when high tensile strength and low elongation is needed. Some of the industries that use Bluing Metal strapping band are construction, agriculture and military.
Bluing Metal Steel strapping band is made from ordinary carbon structured or high-quality carbon structure steels via cold-rolled,elec-tric heat and blued and painted & waxed. The painted and waxed Metal strapping band is the further process fror the Bluing Metal strapping band To prevent rust,the painted Metal strapping band is very better than the blue tem pered Metal strapping band. It is applicable for bundling and packing of wood,paper,glass,stone,welded pipe and so on and other large obiects. Wound type of product: Rib-bon wound Metal strapping band and oscillated wound Metal strapping band.
Bluing Metal Steel strapping band is to heat treatment the steels at about 200 degree centigrade and make the steel surface to form a layer of dense ferroferric oxide film. Bluing Metal strapping band Dense ferroferric oxide film can film the steel body isolated from air and water, and have the effect of anti rust.
The Details of Steel Strapping Band BWG25 X 5/8" SS Band 0.5x16mm Metal Packing
|
Product Color |
Black,Bluing,Painted,White |
|
Surface Finish |
Bluing & oiled , Bluing & waxed , Black , Primary colors(white belt) , Galvanized |
|
Material |
High tensile steel Q195 / Q235 / Q345B / DB460 / |
|
Tensile strength |
(Q195)550-700Mpa / (Q235)680-780Mpa / (Q345)780-880Mpa /(DB460)880-980Mpa |
|
Enwind type |
Ribbon / oscillated Metal strapping |
|
Elongation |
3-6% / 6-8% / 8-12% |
|
Width |
9.5,10.2,11,12,12.7,15,16,17,17.25,19,22,24,25,25.4, 31,31.75,32,40,45mm (Width tolerance:±0.1mm) |
|
Thickness |
0.27-1.5mm (Thickness tolerance:±0.02mm) |
|
Inner diameter |
200 / 300 / 406mm |
| Metal strapping band Size | Strength* | Strap Finish | Coil Winding | Coil Weight | |||||
| width | gauge | ||||||||
| mm | inch | mm | inch | N | lbs | kg | lbs | ||
| 15.9 | 5/8 | 0.51 | 0.020 | 8540 | 1,920 | Painted & Waxed | Mill | 47.6 | 105 |
| 15.9 | 5/8 | 0.58 | 0.023 | 9790 | 2,200 | Painted & Waxed | Mill | 47.6 | 105 |
| 19.0 | 3/4 | 0.51 | 0.020 | 10230 | 2,250 | Painted & Waxed | Mill | 47.6 | 105 |
| 19.0 | 3/4 | 0.58 | 0.023 | 11740 | 2,600 | Painted & Waxed | Mill | 47.6 | 105 |
| 19.0 | 3/4 | 0.64 | 0.025 | 12450 | 2,800 | Painted & Waxed | Ribbon | 47.6 | 105 |
| 19.0 | 3/4 | 0.64 | 0.025 | 12450 | 2,800 | Painted & Waxed | Mill | 34.0 | 75 |
| 19.0 | 3/4 | 0.64 | 0.025 | 12450 | 2,800 | Zinc | Mill | 47.6 | 105 |
| 19.0+ | 3/4+ | 0.74 | 0.029 | 14900 | 3,350 | Painted & Waxed | Ribbon | 47.6 | 105 |
| 19.0+ | 3/4+ | 0.74 | 0.029 | 15125 | 3,400 | Painted & Waxed | Ribbon | 34.0 | 75 |
| 25.1^ | 1^ | 0.80 | 0.031 | 20700 | 4,655 | Painted & Waxed | Ribbon | 49.9 | 110 |
| 31.8 | 1-1/4 | 0.64 | 0.025 | 21350 | 4,800 | Painted & Waxed | Ribbon | 49.9 | 110 |
| 31.8+ | 1-1/4+ | 0.74 | 0.029 | 24910 | 5,600 | Painted & Waxed | Ribbon | 49.9 | 110 |
| 31.8+ | 1-1/4+ | 0.74 | 0.029 | 25000 | 5,600 | Zinc | Ribbon | 49.9 | 110 |
| 31.8 | 1-1/4 | 0.79 | 0.031 | 25132 | 5,650 | Painted & Waxed | Ribbon | 49.9 | 110 |
| 31.8 | 1-1/4 | 0.89 | 0.035 | 29630 | 6,660 | Painted & Waxed | Ribbon | 49.9 | 110 |
| 31.8^ | 1-1/4^ | 1.00 | 0.039 | 32200 | 7,239 | Painted & Waxed | Ribbon | 49.9 | 110 |
| 31.8 | 1-1/4 | 1.12 | 0.044 | 37590 | 8,450 | Painted & Waxed | Ribbon | 49.9 | 110 |
