Zinc Coated Corrugated Roofing Sheet Gi Coil Galvanized Steel With Long Service Life
Zinc Coated GI Steel Coil for Corrugated Roofing Sheet with Long Service Life
Hot Dipped Galvanized Steel Sheet in Coil (GI) is produced by passing the Full Hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. It has excellent corrosion resistance, paintability, and workability due to Zinc’s characteristic. Usually hot dipped galvanized steel sheet and galvanized steel coil process and specifications are basically the same
Galvanized Steel Coil Specification:
| Product Name | Galvanized Steel Coils | ||
| Steel Grade | JIS G3302-SGCC-SGC570, SGCH (FULL HARD-G550) ,DX51D+Z, DX53D+Z ect. | ||
| Type | Coil/Sheet/Plate/Strip | ||
| Thickness | 0.12-2mm,or customer's requirement | ||
| Width | 80mm-1250mm, according to customer's requirement | ||
| Surface Treatment | Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U) | ||
| Surface Structure | Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS) | ||
| Package | Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement | ||
Galvanized Steel Coil Size:
| Thickness (mm) |
Width (mm) |
Mass of Coating (g/m2) |
Thickness (mm) |
Width (mm) |
Mass of Coating (g/m2) |
| 0.25 | 1000/1250 | 40~275 | 0.95 | 1000/1250 | 40~275 |
| 0.30 | 1000/1250 | 40~275 | 0.98 | 1000/1250 | 40~275 |
| 0.35 | 1000/1250 | 40~275 | 1.00 | 1000/1250 | 40~275 |
| 0.36 | 1000/1250 | 40~275 | 1.10 | 1000/1250 | 40~275 |
| 0.40 | 1000/1250 | 40~275 | 1.15 | 1000/1250 | 40~275 |
| 0.42 | 1000/1250 | 40~275 | 1.20 | 1000/1250 | 40~275 |
| 0.45 | 1000/1250 | 40~275 | 1.35 | 1000/1250 | 40~275 |
| 0.47 | 1000/1250 | 40~275 | 1.40 | 1000/1250 | 40~275 |
| 0.50 | 1000/1250 | 40~275 | 1.50 | 1000/1250 | 40~275 |
| 0.55 | 1000/1250 | 40~275 | 1.55 | 1000/1250 | 40~275 |
| 0.58 | 1000/1250 | 40~275 | 1.60 | 1000/1250 | 40~275 |
| 0.60 | 1000/1250 | 40~275 | 1.75 | 1000/1250 | 40~275 |
| 0.65 | 1000/1250 | 40~275 | 1.8 | 1000/1250 | 40~275 |
| 0.70 | 1000/1250 | 40~275 | 1.85 | 1000/1250 | 40~275 |
| 0.75 | 1000/1250 | 40~275 | 1.90 | 1000/1250 | 40~275 |
| 0.80 | 1000/1250 | 40~275 | 1.95 | 1000/1250 | 40~275 |
| 0.85 | 1000/1250 | 40~275 | 1.98 | 1000/1250 | 40~275 |
| 0.90 | 1000/1250 | 40~275 | 2.00 | 1000/1250 | 40~275 |
| 2.50 | 1000/1250 | 40~275 |
Galvanized Steel Coil Application:
- Building & Construction:Roofing; Terrace; Window Frame;
- Door: Rolling-up Door; Shutter; Mobile House;
- Interior Decorations: Wall; Door Frame; Steel Structure; Screen; Ceiling;Elevator;
- Household Appliances: Fridge; Washing Machine; Microwave Oven; Air-Conditioner; Duplicating Machine,etc;
- Transportation: Auto Panel; Interior Decorative Panel; Carriage Panel;
Galvanized Steel Coil Common Package:
Waterproof Kraft Paper + Wooden Pallet (each 3 tons) + Bundle with steel strip.
Or Package can also according to your requirements.
