FRP T Shape Profile Glassfiber H/I Beam Building Material
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
FRP T shape profile Glassfibre H/I beam Building Material
FRP pultrusion production is a continuous production process for producing glass fiber reinforced polymer profiles with arbitrary length and constant cross-section. The reinforcing fiber can be roving, continuous felt, woven fabric, carbon or other. The fiber is impregnated with polymer matrix (resin, mineral, pigment, additive) and passes through the pre-forming station, which generates necessary layering to give the required properties of the profile. After the pre-forming step, the resin impregnated fiber is pulled through the heating mold to polymerize the resin.
| Feature | Application |
| Corrosion resistance | Oil and gas |
| Non-conductive (heat and electricity) | Wastewater treatment |
| Light weight | Power plant |
| High strength | Construction engineering |
| anti-aging. | Food processing |
| Long life cycle | Chemical industry |
Avaliable size
| I/H beam | |
| Width/Height/Thickness mm | Weight g/m |
| 6×6 | 61 |
| 8.5×Φ13 | 175 |
| 11×Φ15 | 243 |
| 12×15 | 220 |
| 12×19 | 270 |
| 15×25.4 | 400 |
| 15×38 | 626 |
| 25×50.8 | 655 |
| 30*50 | 620 |
| 150×150×10 | 8800 |
| 150×150×12 | 11200 |
| 200×200×15 | 18500 |
| T beam | |
| Spec mm | Weight g/m |
| 16×25 | 395 |
| 16×30 | 415 |
| 66×34×5 | 844 |
Package & Delivery
Packing Shipping
1.Carton + pallet 1.Waterway transportation
2.Export wooden box 2.air transport
Manufacturing Technique
| Glass Fiber + Resin System | |||||
| Part No | Resin Base | Application | Temperature resistance | Corrossion resistance | Flame resistance |
| VE | Vinyl Ester | Superior Corrosion Resistance and fire retardant | Very Good | Excellent | Very Good |
| ISO | Isophthalic Polyester | Industrial grade corrosion resistance and fire retardant | Good | Good | Good |
| ORTHO | Orthophthalic resin | Moderate corrosion resistance and fire retardant | Common | Common | Common |
| EPOXY | EPOXY Resin | ||||
Our Company
Shengze is a leading and profession manufacturer of fiberglass products for over 20 years. The main products are various kinds of FRP pultrusion profiles, SMC products , FRP hand lay out product and vacuum infusion products. The annual production capacity is about 8,000 tons.
![FRP T Shape Profile Glassfiber H/I Beam Building Material]()
![FRP T Shape Profile Glassfiber H/I Beam Building Material]()
![FRP T Shape Profile Glassfiber H/I Beam Building Material]()
Main Processing Technic Products Advantage
1.Protruded Profile / Continuous Formation 1.High Voltage Protruded profile and Hand Layup Shell
2.SMC / BMC Molding Products 2.Professional engineer with Design support with 24 years experienc
3.Hand layup Products (Option: With Pattern Print) 3.Customize Large size Products.
4.RTM / Infusion With air bag 4.One-stop service (Purchase/ Order / Tranportation )
FAQ
Q:Are you trading company or manufacturer ?
A:We are factory and trade company
Q:How long is your delivery time?
A:Generally it is 5-10 days if the goods are in stock.Or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q:Do you provide samples ?Is it free or extra ?
A:Yes, we could offer Certain sample for free charge but do not pay the cost of freight.
Please contact me to confirm.
Q:What is your terms of payment ?
A:Payment<=3000USD, 100% in advance.Payment>3000USD, 30% T/T in advance ,balance before shippment.
If you have other question, pls feel free to contact us as below:
