CE Certified with PP material for Float level switch LS-P1085 with vertical installation in NO switching type
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Float Level Switch
Specification:Model NO. LS-P1085 Installation Vertical Switching Type NO ( Normally Open ) Material PP Working Temperature -10~80℃ Wire Gauge UL 1007 22AWG Wire Length 300mm Switching Voltage 110 VDC Switching Current 0.5A Contact Rating 10W
1.Float level switch is widely used in tank level auto control system, startup and shutdown the water pump or electric valve on the basis of liquid level.
2.Vertical installation switch can be mounted on the top or bottom of liquid tank; side installation switch can be mounted on the wall of liquid tank.
3.Switching type definition:
NO: Normally open,mounted switch on the top of tank, switching ON when float rising .
NC: Normally close,mounted switch on the top of tank, switching OFF when float rising.
