Aluminum Finned Fridge Freezer Condenser Coils copper R22 Evaporator
Product Description
1. Material: copper, aluminum, galvanized plate.
2. Copper pipe: diameterΦ7, Φ7.94, Φ9.52, inner grooved or smooth tube.
3. Aluminum foil: hydrophilic or bare
4. Fin type: louver fin, flat fin, corrugated fin
5. Pitch of fins: Ø7 1.1~1.8mm Ø7.94 1.4~2.0 mm Ø9.52 1.4~2.3 mm
6. Pitch of holes and pitch of rows: 20.5x12.7mm, 22x19.05mm, 21x12.7mm, 25.4x22mm equilateral triangle arrangement.
| Specifications of evaporator | ||||
| NO | Tube Diameter(mm) | Distance of hole/row(mm) | Fin Style | Fin Space(mm) |
| 1 | Φ7 | 21*12.7 | Louvered fin,Plain fin,Sine wave fin | 1.4~2.0 |
| 2 | Φ7 | 21*18.9 | Sine wave fin,Corrugated fin | 1.3~1.9 |
| 3 | Φ7 | 25*21.65 | Louvered fin | 1.5~3.8 |
| 4 | Φ9.52 | 25.4*22 | Louvered fin,Sine wave fin | 1.6~6.35 |
| 5 | Φ9.52 | 25.4*22 | Louverd fin,Plain fin,Sine wave fin | 1.6~3.2 |
| 6 | Φ9.52 | 25*19 | Louverd fin,Plain fin,Sine wave fin | 1.4~3.2 |
| 7 | Φ9.52 | 25*21.65 | Louvered fin,V ripple fin | 2.0~3.8 |
| 8 | Φ9.52 | 25*25 | Plain fin | 1.6~3.2 |
| 9 | Φ9.52 | 25*21.65 | Plain fin | 2.0~6.0 |
| 10 | Φ9.52 | 25.4*22 | Louvered fin,Plain fin,Sine wave fin | 1.6~6.35 |
| 11 | Φ9.52 | 31.75*27.5 | Louvered fin,Plain fin,Sine wave fin | 1.6~6.35 |
| 12 | Φ12.7 | 31.75*27.5 | Plain fin,Sine wave fin,V ripple fin | 1.8~6.0 |
| 13 | Φ12.7 | 31.75*27.5 | Louvered fin,Plain fin,Sine wave fin,V ripple fin | 1.7~2.2 |
| 14 | Φ12.7 | 31.75*27.5 | corrugated fin | 1.6~2.9 |
| 15 | Φ15.88 | 38.1*33 | Plain fin,Sine wave fin,V ripple fin | 2~4 |
| 1.5~4.1 | 1.5~4.2 | 1.5~4.3 | 1.5~4.4 | 1.5~4.5 |
We can serve for more types of evaporator according to every customers' drawing and requirement
| Series 1 | Series 2 | Series 3 | Series 4 | |
| Tube Diameter | Φ 9.52 | Φ9.52 | Φ7 | Φ 7.94 |
| Hole Space(mm) | 25 | 25.4 | 20.5 | 22 |
| Row Space(mm) | 21.65 | 22 | 12.7 | 19.05 |
| Tube Material | Copper, Aluminum | Copper, Aluminum | Copper, Aluminum | Copper, Aluminum |
| Type of Tube | Smooth Tube, Inner Grooved Tube |
Smooth Tube, Inner Grooved Tube |
Smooth Tube, Inner Grooved Tube |
Smooth Tube, Inner Grooved Tube |
| Fin Surface | Louver Fin, Corrugated Fin |
Flat Fin, Louver Fin, Corrugated Fin |
Flat Fin, Louver Fin |
Louver Fin |
| Fin Type | Hydrophilic Foil, Bare Foil, Copper Foil |
Hydrophilic Foil, Bare Foil, |
Hydrophilic Foil, Bare Foil, Golden Foil |
Hydrophilic Foil, Bare Foil, Golden Foil |
| Fin Thickness(mm) | 0.095~0.2 | 0.095~0.2 | 0.095~0.2 | 0.095~0.2 |
| Fin Space(mm) | 1.4~2.3 mm | 1.4~2.3 mm | 1.1~1.8mm | 1.4~2.0 mm |
Blown coils have cost homeowners a lot due to costly repairs in the past. But, with routine upkeep and periodic inspections, homeowners can identify issues early and stop further damage.
Be cool and save money at the same time – go for an energy-efficient air conditioning system! It’s the green way!
