Cold Room Finned Tube Heat Exchanger Evaporator Coil Pipe
Product Description
Maintenance is essential too! Dirty or debris buildup on the coils can lower efficiency and cause system breakdowns. Clean coils, quality filters and regular upkeep boost efficiency and extend the life of your air conditioning system.
So, keep your coils in good shape! It’ll help achieve optimal performance and maximum comfort in any indoor space.
1. Material: copper, aluminum, galvanized plate.
2. Copper pipe: diameterΦ7, Φ7.94, Φ9.52, inner grooved or smooth tube.
3. Aluminum foil: hydrophilic or bare
4. Fin type: louver fin, flat fin, corrugated fin
5. Pitch of fins: Ø7 1.1~1.8mm Ø7.94 1.4~2.0 mm Ø9.52 1.4~2.3 mm
6. Pitch of holes and pitch of rows: 20.5x12.7mm, 22x19.05mm, 21x12.7mm, 25.4x22mm equilateral triangle arrangement.
| Specifications of evaporator | ||||
| NO | Tube Diameter(mm) | Distance of hole/row(mm) | Fin Style | Fin Space(mm) |
| 1 | Φ7 | 21*12.7 | Louvered fin,Plain fin,Sine wave fin | 1.4~2.0 |
| 2 | Φ7 | 21*18.9 | Sine wave fin,Corrugated fin | 1.3~1.9 |
| 3 | Φ7 | 25*21.65 | Louvered fin | 1.5~3.8 |
| 4 | Φ9.52 | 25.4*22 | Louvered fin,Sine wave fin | 1.6~6.35 |
| 5 | Φ9.52 | 25.4*22 | Louverd fin,Plain fin,Sine wave fin | 1.6~3.2 |
| 6 | Φ9.52 | 25*19 | Louverd fin,Plain fin,Sine wave fin | 1.4~3.2 |
| 7 | Φ9.52 | 25*21.65 | Louvered fin,V ripple fin | 2.0~3.8 |
| 8 | Φ9.52 | 25*25 | Plain fin | 1.6~3.2 |
| 9 | Φ9.52 | 25*21.65 | Plain fin | 2.0~6.0 |
| 10 | Φ9.52 | 25.4*22 | Louvered fin,Plain fin,Sine wave fin | 1.6~6.35 |
| 11 | Φ9.52 | 31.75*27.5 | Louvered fin,Plain fin,Sine wave fin | 1.6~6.35 |
| 12 | Φ12.7 | 31.75*27.5 | Plain fin,Sine wave fin,V ripple fin | 1.8~6.0 |
| 13 | Φ12.7 | 31.75*27.5 | Louvered fin,Plain fin,Sine wave fin,V ripple fin | 1.7~2.2 |
| 14 | Φ12.7 | 31.75*27.5 | corrugated fin | 1.6~2.9 |
| 15 | Φ15.88 | 38.1*33 | Plain fin,Sine wave fin,V ripple fin | 2~4 |
| 1.5~4.1 | 1.5~4.2 | 1.5~4.3 | 1.5~4.4 | 1.5~4.5 |
We can serve for more types of evaporator according to every customers' drawing and requirement
| Series 1 | Series 2 | Series 3 | Series 4 | |
| Tube Diameter | Φ 9.52 | Φ9.52 | Φ7 | Φ 7.94 |
| Hole Space(mm) | 25 | 25.4 | 20.5 | 22 |
| Row Space(mm) | 21.65 | 22 | 12.7 | 19.05 |
| Tube Material | Copper, Aluminum | Copper, Aluminum | Copper, Aluminum | Copper, Aluminum |
| Type of Tube | Smooth Tube, Inner Grooved Tube |
Smooth Tube, Inner Grooved Tube |
Smooth Tube, Inner Grooved Tube |
Smooth Tube, Inner Grooved Tube |
| Fin Surface | Louver Fin, Corrugated Fin |
Flat Fin, Louver Fin, Corrugated Fin |
Flat Fin, Louver Fin |
Louver Fin |
| Fin Type | Hydrophilic Foil, Bare Foil, Copper Foil |
Hydrophilic Foil, Bare Foil, |
Hydrophilic Foil, Bare Foil, Golden Foil |
Hydrophilic Foil, Bare Foil, Golden Foil |
| Fin Thickness(mm) | 0.095~0.2 | 0.095~0.2 | 0.095~0.2 | 0.095~0.2 |
| Fin Space(mm) | 1.4~2.3 mm | 1.4~2.3 mm | 1.1~1.8mm | 1.4~2.0 mm |
