OCTG Pipe API 5CT 9-5/8 inch HC L80 BC-SCC Steel Casing Oil Casing Tubular Goods for Oil and Gas
Product Description
Product Description
| Steel Tube name | OCTG Pipe API 5CT 9 5/8 K55 J55 L80 N80 P110 High Collapse BTC-SCC Steel Tubing & Casing Oil Casing Tubular Goods for Oil and Gas |
| Outside Dia(mm) | 48.26-406.4mm |
| Wall Thickness(mm) | 3.18-22.22mm |
| Length | R1/R2/R3 |
| Thread Type | BC/LC/SC/OTHER |
| Standard | API 5CT /API 5B |
| Material | J55,K55,N80,L80-1,C90,R95,P110,BT110T,Q125 |
| Surface | Black painting, varnish paint, anti rust oil, 3PE,etc |
| Packaging | Loose package, packaged in bundles(3Tons Max) , bundled pipes with two slings at both ends for easy loading and discharging, end with plastic caps or as per customers’ requirements |
| Application | Borewell casing pipe api 5ct 9 5/8 oil well bore steel casing and tubing for borewell |
| 9 5/8'' Seamless Steel Casing pipe Details | |||||
| Inch | Lb/Ft | PPF | OD(mm) | kg/m | WT(mm) |
| 9 5/8 inch | 32 lb/ft | 32 ppf | 244.48mm | 48.07kg/m | 7.92mm |
| 9 5/8 inch | 36 lb/ft | 36 ppf | 244.48mm | 53.57kg/m | 8.94mm |
| 9 5/8 inch | 40 lb/ft | 40 ppf | 244.48mm | 59.53kg/m | 10.03mm |
| 9 5/8 inch | 43.5 lb/ft | 43.5 ppf | 244.48mm | 64.73kg/m | 11.05mm |
| 9 5/8 inch | 47 lb/ft | 47 ppf | 244.48mm | 69.94kg/m | 11.99mm |
| 9 5/8 inch | 53.5 lb/ft | 53.5 ppf | 244.48mm | 79.62kg/m | 13.84mm |
| 9 5/8 inch | 58.4 lb/ft | 58.4 ppf | 244.48mm | 86.91kg/m | 15.11mm |
| 9 5/8 inch | 59.4 lb/ft | 59.4 ppf | 244.48mm | 88.4kg/m | 15.47mm |
| 9 5/8 inch | 64.9 lb/ft | 64.9 ppf | 244.48mm | 96.58kg/m | 17.07mm |
| 9 5/8 inch | 70.3 lb/ft | 70.3 ppf | 244.48mm | 104.62kg/m | 18.64mm |
| 9 5/8 inch | 75.6 lb/ft | 75.6 ppf | 244.48mm | 112.5kg/m | 20.24mm |
Application
IMRISTEEL can provide you with OCTG casing pipe and tubing pipe in such grades as H40, J55, K55, N80-1, N80Q, L80-13Cr, R95, C90, T95, C110, P110, Q125 according to API 5CT certificate. Besides, we can also produce such as BTC, LTC, STC thread and special threads, etc. Welcome to contact us if you have any project , I will serve you the best products and service.
Inner Mongolia Rational Industry Limited(IMRI)is a supplier of anti-corrosion coating steel pipe and seamless steel pipes. We have two production lines for external anti-corrosion coating, one production line for internal coating and one production line for insulating tubes. We mainly engage in accessory processing for Baotou Steel, which is the top 3 manufacturer of seamless steel pipe in China. At the same time, IMRI is a first-class distributor of Baotou Steel’s steel products. We have established a long-term strategic co-operation relationship with Baotou Steel.
Baotou Steel's Plant Area
Baotou Steel has 5 carbon seamless steel pipe production lines and 4 steel pipe heat treatment lines. Two of the world's most advanced PQF three-roll automatic rolling production line, one MPM two-roll automatic rolling production line. It can produce various kinds of carbon seamless steel pipe, including OCTG steel casing and tubing pipe, line pipe, low/high pressure boiler tube, hydraulic pillar tube, high pressure gas cylinder steel pipe, structure pipe, fluid conveying steel pipe, fitting, axle tube, rectangular tube, and so on. It can produce carbon seamless steel pipe in outer diameter from 38 mm to 457 mm, wall thickness from 2.9 mm to 60 mm with 180 tons annual output.
WHY CHOOSE US ?
API 5L, API 5CT, API 5DP, TUV, ISO, CCS certificated qualification and extreme standard let us keep very competitive in the current seamless steel pipe market. So there is no need for you to worry about the products quality.
Contact Us
We can provide OEM service.If you need any kind of the steel pipes for water, oil and gas transportation ,petroleum casing & tubing,railway rails,etc. please feel free to contact us.
