Fusion Bond Epoxy Powder ISO21809 Anti Corrosion Coating Materials
Price:
$1,180.00/tons >=10 tons
MOQ:
10 tons
Delivery Time:
Negotiable
Brand:
IMRI
Product Description
Product Description
Product Features
This type of powder coating is a thermosetting pure epoxy powder coating ,it is suitable for three-layer polypropylene(3PP) anti-corrosion layer . The epoxy powder coating is used as the bottom layer, which has excellent adhesion and cathodic disbonding resistance. The coating forms a good anti-corrosion system which resist high temperature, various chemicals such as acid, alkali and salts and external damage. Compared with the anti-corrosion structure of the 3PE,It has a wider temperature range.Currently, it is a major long-lasting anticorrosive material.
Specification
Varieties | Standard | Application |
3LPE | DIN30670,NF A49-710, CAN/CSA Z245.21, ISO DIS21809-1, GB/T23257 etc | Long-distance buried pipeline for oil, water and gas etc normal operating temperature: 60℃,high operating temperature:80℃ |
3LPP | DIN30670,NF A49-711 etc | Long-distance buried pipeline for oil, water and gas etc operating temperature: -20℃-110℃ |
FBE/DPS | SY/T0315, CAN/CSA Z245.20, AWWA C213, Q/CNPC38 etc | Long-distance anti-corrosion internal and external surface of pipeline on land and underwater |
Liquid epoxy | API PR-5L2, ISO15741 etc | Long-distance and resistance-reducing transmission pipelines |
PU foam thermal insulation coating | GB/T 50538, EN253 etc | Industry pipes in heat preservation, cold insulation engineering etc |
Weather resistance coating | CAN/CSA Z245.20 etc | widely used in aerial pipeline with more than 20 year's service life |
Epoxy coal tar coating | SY-T0447, SPEC | Sewage pipe, sea and wetland pile pipe etc |
Coating for flight oil(epoxy novolac) | SPEC | Transportation of aviation kerosene, gasoline, diesel, chemical reagent etc |
Protective coating | SPEC | used under complex working condition |
High solid epoxy wearesisting coating | ISO 12944, ASTM, AWWA, EN10289 etc | generally unsed for pile pipe and through pipe |
Tubing&drill internal coating | SY/T 0544,SY/T6717,SPEC, etc | This coating has excellent anti-corrosion and mechanical properties |
Company Profile
IMRI is a FBE powder coating design service supplier. FBE coating material is thermosetting material, it is consist of solid epoxy resin, curing agent and various additives by mixing, grinding. When performing, steel tube was heated to 220-230 degree centigrade, then FBE powder is sprayed on the surface of the pipe by electrostatic adsorption method, FBE powder is heated and cooled melt adhesive curing.Our company supplies many kinds of anti-corrosion materials,steel pipes,such as FBE,DPS,2LPE,2LPP,3LPE and 3LPP coating steel pipes as well as bare steel pipes.
Customer Photos
Packing & Delivery
Precautions
· Storage conditions:It is stored in a dry, ventilated environment below 30 ℃. During this time, it must not be near the heat source.
· After the package is opened for use, the unused portion must be repackaged to prevent moisture absorption from the air.
· Transportation condition:Direct sunlight and rain must be prevented during transportation. When the temperature is above 35℃, it should take insulation measures.
· Conditions of use: Before coating, the surface treatment of steel pipes should meet the requirements of
· GB/T 8923.1. After the surface treatment, the wall of the pipe must be coated within 4 hours.
· Construction safety: Although this product is non-toxic, non-polluting and not easy to burn, measures should be taken to prevent a large amount of inhalation during construction.
· After the package is opened for use, the unused portion must be repackaged to prevent moisture absorption from the air.
· Transportation condition:Direct sunlight and rain must be prevented during transportation. When the temperature is above 35℃, it should take insulation measures.
· Conditions of use: Before coating, the surface treatment of steel pipes should meet the requirements of
· GB/T 8923.1. After the surface treatment, the wall of the pipe must be coated within 4 hours.
· Construction safety: Although this product is non-toxic, non-polluting and not easy to burn, measures should be taken to prevent a large amount of inhalation during construction.
