Long Life Quality Multi V Belt Pk Belt From Factory
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
We are the factory of rubber product, HEIYI RUBBER Co.,Ltd supply belts since 1995,
specializing in various of V belt(Fan Belt,Raw Edge V Belt,Variable Speed Belt,Joint V Belt), .
Use for agriculture,industrial and automotive. Customized service can be offered at any time.
specializing in various of V belt(Fan Belt,Raw Edge V Belt,Variable Speed Belt,Joint V Belt), .
Use for agriculture,industrial and automotive. Customized service can be offered at any time.
Specification of V Belt
Model | Top Width(mm) | Thickness(mm) | Length Range(inch) | Length Range(mm) | Angle |
| O/AV10* | 10 | 8.5 | 19.68"-216.5" | 500-12000 | 40° |
| A/AV13* | 13 | 9.5 | 19.68"-216.5" | 500-12000 | 40° |
| B/AV17* | 17 | 14 | 19.68"-216.5" | 500-12000 | 40° |
| C/AV22* | 22 | 19 | 19.68"-216.5" | 500-12000 | 40° |
| SAx/LAx | 12.5 | 8.8 | 19.68"-216.5" | 500-12000 | 38° |
| SBx/LBx | 16.2 | 10 | 19.68"-216.5" | 500-12000 | 38° |
| SCx/LCx | 21 | 11.2 | 19.68"-216.5" | 500-12000 | 40° |
| XPA/SPAX | 12.5 | 10 | 19.68"-216.5" | 500-12000 | 40° |
| XPB/SPBX/5V | 16.2 | 13 | 19.68"-216.5" | 500-12000 | 40° |
| XPC/SPCX | 21 | 15 | 19.68"-216.5" | 500-12000 | 40° |
| XPZ/SPZX/3V | 9.5 | 8.8 | 19.68"-216.5" | 500-12000 | 40° |
| 25N/8V | 25 | 17 | 19.68"-216.5" | 500-12000 | 40° |
| HI | 25 | 13 | 19.68"-216.5" | 500-12000 | 32° |
| HJ/HDJ | 32 | 18 | 19.68"-216.5" | 500-12000 | 32° |
| HD | 32 | 18 | 19.68"-216.5" | 500-12000 | 40° |
| HK | 38 | 20 | 19.68"-216.5" | 500-12000 | 32° |
| HL | 45 | 24 | 19.68"-216.5" | 500-12000 | 32° |
| HM | 51 | 25.5 | 19.68"-216.5" | 500-12000 | 32° |
| HN | 57 | 26 | 19.68"-216.5" | 500-12000 | 32° |
| HO | 63 | 26 | 19.68"-216.5" | 500-12000 | 32° |
| 9J-5 | 50.1 | 11 | 19.68"-216.5" | 500-12000 | 40° |
| 9J-6 | 60.4 | 11 | 19.68"-216.5" | 500-12000 | 40° |
| 9J-7 | 70.7 | 11 | 19.68"-216.5" | 500-12000 | 40° |
| 3R-5V | 50 | 15.2 | 19.68"-216.5" | 500-12000 | 40° |
| 4R-5V | 67.5 | 15.2 | 19.68"-216.5" | 500-12000 | 40° |
| 4R-SPA | 60.8 | 11 | 19.68"-216.5" | 500-12000 | 38° |
| 2HB | 35 | 14 | 19.68"-216.5" | 500-12000 | 38° |
| 3HB | 54 | 14 | 19.68"-216.5" | 500-12000 | 38° |
| 4HB | 72.5 | 14 | 19.68"-216.5" | 500-12000 | 38° |
| 5HB | 91 | 14 | 19.68"-216.5" | 500-12000 | 38° |
| 6HB | 110 | 14 | 19.68"-216.5" | 500-12000 | 38° |
| 2HC | 47.5 | 16 | 19.68"-216.5" | 500-12000 | 38° |
| 3HC | 72.5 | 16 | 19.68"-216.5" | 500-12000 | 38° |
| 4HC | 98 | 16 | 19.68"-216.5" | 500-12000 | 38° |
AA,BB,CC Belts are also available, if you have any need of them, please feel free to contact us. We
will confirm all the details and reply you within 24 hours.
Structure of V Belt
| Function | Material | |
| Tension Member | The treated polyester cord is a low stretch high strength tension member able to withstand shock loads on drives with fixed centers | Polyester/Aramid Fiber |
| Rubber Ribs/Teeth | Long wearing, oil resistant, fibre-loaded neoprene rubber is used in the ribs to provide support for the tension member and to transmit the loads to the pulley | EPDM |
| Backing Material | Bias ply type fabric backing resists cracking and provides abrasion resistance | EPDM |
| Insulation Material | oil and heat resistant rubber is used to bond the tension member to the rest of the belt | EPDM |
the order.
Advantages
. Thousands of moulds available. MOQ is based on one mould quantity
. ISO/TS16949 quality certificate
. Warranty(Auto belt):150,000-200,000kms
. We could supply a whole series of auto belts and agricultural belts,We have our own brand accept OEM
Product Description
. Excellent flexibility
. High power transmission efficiency
. Lower noise
. High grade engineered rubber
. Longer service life
. Temperature range from -40ºC to +120ºC
. Oil, heat,ozone and abrasion resistant
FAQ
Q1. Can I have a sample order?
Yes, any sample order is welcomed to know the quality of our products.
Q2. What about the lead time of the sample or the final order?
2-5 days for normal sample.
20-30 days for a formal order.
For large quantity, lead time can be negotiated.
Q3. How much is the minimum quantity for each item in one order?
One mould quantity is ok. Usually around 50pcs for small item, 10-20pcs for big item.
Q4. Is it possible to print our logo or brand on the belt?
Yes, we can print your logo or design on the belt after receipt of your formal authorization letter of the logo or your brand.
Q5. Do you offer the guarantee for your product?
Yes, usually we offer 150000-200000kms warranty for auto belts; for agricultural belt and industril belts, the warranty
will be different according to your quality demand.
Related Products
Packing Our usually packing: Inner plastic bag, outside with carton, outside the carton with woven bag.
Application
Our belts can be used on agriculture machine ,auto machine and industrial machine etc.
Partnership and After-sale serves
We have our own famous brand "HEIYI" brand ,We also accept OEM Brand,
In domestic market:
Our "HEIYI" brand agents and distributors throughout the 31 provinces in China,
In international market
Our products have been exported to over 26 countries , including England, Brazil, Russia, Mexico, Australia,Singapore,India, Pakistan, Vietnam, Nepal, Cambodia,Mongolia, Cameroon and so on.
1.Our customer include:
(1) Import company
(2) Belts wholesaler
(3) Cooperate directly with agriculture machine and auto machine and industrial machine factory etc, to be their
authorized belt supplier.
2.After-sale serves
Our belts warranty time : 150,000-200,000kms
we have professional Service Department, Heiyi can ensure you enjoy a pleasure order experience from
beginning(get in touch with us) to end (receive your goods and after-sale service).
Factory and workshop
46000 Squre meter workshop
Strong technical force; advanced production technology; excellent production equipment. Has 12 agricultural
machinery belt and automobile belt automatic production lines
Thousands of belts moulds in our factory
Quality control and R&D department
1.R & D personnel 10people, professional and technical personnel 20 people Strictly follow ISO/ TS16949:2009
quality management system
2.Professional Quality Control Department, Heiyi can ensure product quality consistently from raw material selection,
semi-finished products inspection, to finished goods.
Certification
We have got ISO/TS16949 quality certificate and 13 patent certificates
