Warehouse Self Propelled Hydraulic Scissor Lift 10m 12m Electric Mobile Aerial Work Platform for Logistics Handling
Warehouse Self Propelled Hydraulic Scissor Lift 10m 12m Electric Mobile Aerial Work Platform for Logistics Handling
Product Specifications:
| Model | Platform Size (mm) |
Rated loading Capacity (kg) | Max Lifting Height (m) | Max Working Height (m) | Overall Size (mm) |
Platform Extension Length (mm) | Power (KW) |
Net Weight (kg) |
| GTJZD03 | 1290*700 | 240 | 3 | 5 | 1435*760*1900 | 0.6 | 900 | |
| GTJZD04 | 1290*700 | 240 | 4 | 6 | 1440*760*2030 | 0.6 | 950 | |
| GTJZ06 | 1670*740 | 230 | 6 | 8 | 1850*790*2200 | 0.9 | 3.3 | 1530 |
| GTJZ-6A | 2300*810 | 380 | 6 | 8 | 2480*810*2180 | 0.9 | 3.3 | 1880 |
| GTJZ-6 | 2300*1130 | 550 | 6 | 8 | 2480*1190*2190 | 0.9 | 3.3 | 2150 |
| GTJZ-8A | 2260*810 | 230 | 8 | 10 | 2480*850*2300 | 0.9 | 3.3 | 2030 |
| GTJZ-8 | 2260*1130 | 450 | 8 | 10 | 2480*1190*2320 | 0.9 | 3.3 | 2300 |
| GTJZ-10 | 2290*1130 | 320 | 10 | 12 | 2495*1181*2450 | 0.9 | 3.3 | 2530 |
| GTJZ-12 | 2290*1130 | 320 | 11.8 | 13.8 | 2495*1187*2585 | 0.9 | 4.5 | 2870 |
| GTJZ-14 | 2670*1130 | 227 | 13.8 | 15.8 | 2840*1400*2595 | 0.9 | 4.5 | 3340 |
Special hydraulic pump station for pump station lifting operation platform.
Install an emergency descent valve, and manually control the descent when the platform is powered off; Built in overflow valve, which can prevent excessive system pressure during upward movement and provide protection function.
Up and down control. Install a safety emergency stop in the control section to maximize the protection of property and personal safety. Each operating part uses 36V safety control voltage.
RFQ
Q. Are you manufacture?
A: Yes,we are factory with more than 10 years of manufacturing experience .
R. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages beforyou pay the balance.
Q. What is your terms of delivery?
A: EXW, FOB,CFR, CIF. Q.How about your delivery time? A:Generally,it will take 7-10 working days after receiving your advance payment.The specific delivery time depends on the item and the quantity of your order.
Q: What is your terms of packing?
A: Generally, we use standard exported wooden case for LCL goods, and fixed well for FCL goods.
Q.Do you test all your goods before delivery?
A:Yes, we have 100% test before delivery.
Q.How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefits;
2.We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from.
