0.1 mm Cold Rolled Hot Dipped Galvanized Color Coated Steel Coil PPGI for Long-Lasting
Prepainted galvanized steel coil (PPGI coil) is one of our main products. Top Metal / RAYIWELL MFG is a leading prepainted galvanized steel coil manufacturer in China. Our factory has three color coating lines, with an annual output of 320,000 tons. Except for PPGI coil, we also offer PPGL steel, color-coated aluminum coil, color-coated stainless steel in coil, sheet, plate, and strip.
Prepainted galvanized steel coil is a type of steel coil that has been coated with a layer of paint. The paint is typically applied to both sides of the coil using a continuous coil coating process. This coating helps to protect the steel from corrosion and provides an aesthetic finish.
The use of prepainted galvanized steel coils can help reduce maintenance costs over time, as the protective coating helps to prevent rust and other forms of corrosion.
Prepainted galvanized steel coils offer a versatile and durable solution for various construction and manufacturing applications.
| Substrate | Galvanized steel |
| Thickness | 0.15 mm-1.2 mm |
| Width | 600 mm-1,250 mm |
| Stock Width | 914mm, 1,200mm, 1,219mm, 1,250 mm, etc. |
| Coil Weight | 3-8 tons (can be customized) |
| Painting Types | PE, SMP, HDP, PVDF |
| Painting Thickness | Top: 11-35 μm Back: 5-14 μm |
| Zinc Coating Thickness | 15-275 g/ |
| Colors | As per RAL Color (custom patterns are available) |
| Package | Standard export package or as per your requirements |
Prepainted galvanized steel sheet is made of electro-galvanized and hot-dip galvanized steel as substrates. After pretreatment (degreasing and chemical treatment), one or more layers of coatings are continuously applied to the surface of the base metal by coil coating and then baked. It includes base metal (cold rolled steel), zinc coating, chemical conversion coating, primer coating, and top coating.
