Universal spring machine Metal Wire Forming machine UnionSpring Machinery Supplier
Price:
Negotiable
MOQ:
1
Delivery Time:
15
Brand:
UnionSpring
Product Description
US-1260R Camless CNC automatic Spring Machine Spring Making Machine
Model | US-1260R |
Axis | 12 |
Wire Diameter | 2.0-6.0mm |
Wire Wheel Sets | 4 Sets |
Slide Axis | 2.7KW*8 |
Wire Feeding Axis | 5.5KW |
Rotary Wire Axis | 4.4KW |
Rotary Quill Axis | 2.0KW |
Spinner Axis | 2.0KW |
Machine Size | 2400*2000*2100mm3 |
Machine Weight | 6000KG |
US-1260R Camless Spring Forming Machine descriptions:
1. Individual servo slides for easy setup and adjustment.
2. High-precision wire feeding box that supports 360°rotation.
3. Simple and efficient straightening device.
3、Straightener
The straightening device ensures that the steel wire after straightening has no internal stress and the steel wire is smooth, which facilitates the subsequent processing work.
4、Machine panel
The eight slides work together, the assembly precision of the parts is high, and the machine runs for a long time.
5、Sanyo motor
Japan imported Sanyo Electric .Features: high precision motor, good stability, maintenance free, long use time
Stretch film winding
Exempt wooden box
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
*Hlep adjust sample
Q: What information should customer provide to get machine offer from UnionSpring? A: Please you usually share below info to check suitable machine. *Specific drawing *Wire material *Additional function you need with the machine ,such as chamfering, threading, etc. We will check best solution and offer for your requests after checking details. Q: How can I know if UnionSpring machine can produce my product precision? A: If you have high precision outputs requests, would you please send check gauge or parts which this outputs will fit, we will set parts for you to fit them. Or we can send samples for you to measure. Q: Is the machine tested before shipment? A: We will do the following tests: 1. Wire feeding accuracy test 2. 360 hours continuous running-in test 3. Machine adjustment test according to customer's products, etc. Q: How can I get training if have no experience about machine? A: We will send manual book with machine and also can send video to show you how to run machine if you have doubts. Q: If computer can set customer own language to let their work to run the machine? A: Surely, we can set two languages in the controller, we can set the language you asked, we just need your help about some key translate to load into controller. Q: What's the purchase process? A: Inquiry-----Ger to know request details -----Offer best solution-----Talk about setup sample process-----Order-----Set sample and send video for checking-----Ship machine . Q: What is your payment term? A: 30% payment in advance as a deposit, and 70% balance before shipment.
