UnionSpring_Tech Flat Wire High Current Power Choke Coil Winding machine US-850
Price:
$28,600.00/sets 1-1 sets
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
UnionSpring
Product Description
UnionSpring_Tech Flat Wire High Current Power Choke Coil Winding machine US-850
Products Description
Model No. | US-850 |
Wire diameter | T: 0.3-5.0mm W: 3.0-15.0mm W*T: 40mm2 |
Max. working length of wire feeder | 130mm |
Winding direction | R/L direction |
Wire feeding axis servo | 0.4kw |
Wire axis setting range | 0.1⁰-2359.9⁰ |
Winding axis servo | 2.0kw |
Lifting axis setting range | 0.1-40 |
Lifting axis servo | 2.0kw |
Dimension (L*W*H) | 1750*1250*2000mm |
Weight | 900kg |
US-850 CNC Winding Machines Features:
2. The machine adopts an independent wire feeding device, which can realize single-time, multiple wire feeding, and wire feeding of any length; the rotating core device is located behind the board surface, and the servo is controlled separately, which can realize 360⁰ rotation in positive and negative directions
3. The winding shaft is directly installed on the arm shaft, and there are 2 sets of servo synchronous control. It can realize
forward and reverse winding, dense winding and variable pitch winding, and can realize single-layer, multi-layer and simple
winding.
4. Imported servo, imported planetary reducer transmission, high operating accuracy
5. The machine adopts windows operation interface, which can save the adjustment parameters of products of various specifications.
3. The winding shaft is directly installed on the arm shaft, and there are 2 sets of servo synchronous control. It can realize
forward and reverse winding, dense winding and variable pitch winding, and can realize single-layer, multi-layer and simple
winding.
4. Imported servo, imported planetary reducer transmission, high operating accuracy
5. The machine adopts windows operation interface, which can save the adjustment parameters of products of various specifications.
Details Images
Working Table
Wire Decoiler
Wire Feeding Wheels
Contriollor
Transformer
Sanyo Motor
Company Profile
Guangdong UnionSpring Machinery Co., Ltd
UnionSpring Machinery is a professional CNC automatic intelligent metal wire/busbar processing machines manufacturer from Guangdong China. In UnionSpring Machinery, there are many kinds of springs machines, spring coiling machines, wire shapes forming machines, inductance/transformer/air coils winding machines, enameled copper wire winding bending forming stripping/peeling machines and copper busbar bending forming winding stripping and punching machines. More higher quality, higher precision and more professional metal wire bus bar processing CNC machines manufactured from here. Including high-effective price CAM style machines or camless style, wire rotary or not wire rotary, with more customized device to realize Integration multi-functional more in one machine. More options can be chosen. Based on the high quality machines and customer service, we also care about-how to realize the optimization of machinery cost and productivity, and then to establish a long-term win-win cooperation relationship you! Welcome to contact us!
Our Workshop
PACKING & SHIPPING
After Sales Service
Pre-Sales Service
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
*Hlep adjust sample
FAQ
Q: What information should customer provide to get machine offer from UnionSpring?
A: Please you usually share below info to check suitable machine.
*Specific drawing
*Wire material
*Additional function you need with the machine ,such as chamfering, threading, etc.
We will check best solution and offer for your requests after checking details.
Q: How can I know if UnionSpring machine can produce my product precision?
A: If you have high precision outputs requests, would you please send check gauge or parts which
this outputs will fit, we will set parts for you to fit them. Or we can send samples for you to measure.
this outputs will fit, we will set parts for you to fit them. Or we can send samples for you to measure.
Q: Is the machine tested before shipment?
A: We will do the following tests:
1. Wire feeding accuracy test
2. 360 hours continuous running-in test
3. Machine adjustment test according to customer's products, etc.
Q: How can I get training if have no experience about machine?
A: We will send manual book with machine and also can send video to show you how to run machine if you have doubts.
Q: If computer can set customer own language to let their work to run the machine?
A: Surely, we can set two languages in the controller, we can set the language you asked, we just need your help about some key translate to load into controller.
Q: What's the purchase process?
A: Inquiry-----Ger to know request details -----Offer best solution-----Talk about setup sample process-----Order-----Set
sample and send video for checking-----Ship machine .
sample and send video for checking-----Ship machine .
Q: What is your payment term?
A: 30% payment in advance as a deposit, and 70% balance before shipment.
