Outdoor ADSS fiber optical cable strong tensile 1-48 core Power Overhead span 50 100 150 200 PE jacket
ADSS optical cable: Non-metal reinforcement, self-supporting, gel filled, polyethylene (PE) inner sheath, Kevlar reinforced, PE outer sheath communication outdoor optical cable
Description
The ADSS single-sheathed cable adopts a stranded loose bushing structure. The fiber is inserted into a loose tube made of a high-modulus polyester material and filled with a waterproof compound. Loose casing (and filler) is twisted with non-metal reinforcement (FRP3) to form a dense structure. The cable core. The cable core is wrapped with water block and twisted with enhanced Kevlar aramid fiber. Finally, extrude the PE sheath or AT) sheath.
Features:
Fiber account: 2 to 144 fiber color code buffer tubes.
Fiber type: Single mode/multi-mode/hybrid
Standards: IEEE-P1222 and IEC 60794-1.
Other versions: Long-span ADSS
Structure: Full dielectric circular typical span length up to 1000M, single sheath or double sheath.
Outer sheath: HDPE or anti-creepage
Maximum tension: Maximum 20000N, long span
Central reinforcement: FRP
Technique Parameter:
| Cable Name | ADSS | Diameter | 9.5MM or Customized |
| MOQ | 2KM | Fiber Type | G652D,G657A1,OM1,OM2,OM3 |
| Armored | Steel wire | Jacket Material | HDPE |
| Attenuation | <0.35 db/KM | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Warranty | 15 year | Cable text | Customer’s company name+Cable information |
| Ordering information | 48 Core ADSS Fiber optical cable, G.652D Fiber, Diameter:9.5mm, length : 2km(customized) | ||
