Product Description
Product Description
Product Introduction
Both XZ-DT25-H(25W) and XZ-DT25-U(100mW) can act as transmitter and receiver. Usually in the wireless telemetry system,XZ-DT25-H acts as a trasmitter,XZ-DT25-U acts as a receiver.XZ-DT25-H can also be made to 50W and 35W.This set is widely used in Wireless Telemetry and GPS positioning system.
Software Program
Technical Parameters
XZ-DT25-H Parameters | ||
Frequency Range | 136～174MHz, 220～240MHz, 410～470MHz | |
Frequency stability | ≤±2.5PPm | |
Transmit Power | 25W | |
Modulation | GFSK/4GFSK | |
Air Data Rate | 1200～115200bps settable by user | |
Baud Rate | 1200～115200bps settable by user | |
Interface | RS232&RS485 default, TTL customized | |
Power Supply | 12V@10A | |
Interface Data Format | 8E1/8N1/801 | |
Receiving Sensitivity | -125dBm@1200bps/-120dBm@9600bps | |
Channel Bandwidth | 10KHZ@1200bps/25KHZ@9600bps | |
Emission Current | ≤150mA | |
Receiving Current | ≤50mA | |
Working Temperature&humidity | -40℃～80℃ (industrial grade),10% to 90% relative humidity, no condensation | |
Dimension(L/W/H) | 145X 86X 40mm | |
Weight(g) | ≤500g | |
XZ-DT25-U Parameters | ||
Frequency Range | 136～174MHz, 220～240MHz, 410～470MHz | |
Frequency stability | ≤±2.5PPm | |
Transmit Power | 100mW | |
Modulation | GFSK/4GFSK | |
Air Data Rate | 1200～115200bps settable by user | |
Baud Rate | 1200～115200bps settable by user | |
Interface | TTL/RS232/RS485 | |
Power Supply | 3.3-5V | |
Interface Data Format | 8E1/8N1/801 | |
Receiving Sensitivity | -125dBm@1200bps/-120dBm@9600bps | |
Channel Bandwidth | 10KHZ@1200bps/25KHZ@9600bps | |
Emission Current | ≤1.5A (Max Output Current is not less than 2A) | |
Receiving Current | ≤80mA | |
Working Temperature&humidity | -40℃～80℃ (industrial grade),10% to 90% relative humidity, no condensation | |
Dimension(L/W/H) | 32 X 20X 7mm | |
Weight(g) | ≤50g | |
Pin Definitions
Software Program
Package Includes
1*25w transmitter
1*program cable
1*power cable
1*clip antenna
3*100mW receiver
3*rubber antenna
3*ECH9 pins cable
Company Profile
Thingsend is committed to the IOT to provide users with a full range of services such as IOT products, cloud platforms and overall solutions.OEM&ODM service are supported.
Thingsend is integrated with R&D, production and sales. And products integrate sensors, batteries, and wireless transmission with low-power intelligent management, forming an out-of-the-box wireless smart sensor. Sensor types cover temperature, temperature and humidity, gas, soil moisture, industrial site monitoring, etc., and our sensors are widely used in cold storage, cold chain, smart agriculture, digital factories, smart buildings, energy and chemical industries. Thingsend has a professional R&D team, many RF test instruments and mature communication solutions such as NB-IoT, LoRa, Wi-Fi, BLE, ZigBee, etc., which can provide customers with in-depth industry solutions in a short time.
