Delivery length: 4m
Motor power: 1.5kw
Speed: 25r/min
Can be customized.
500-2500kg/H Output Plastic Recycling Machine For Washing Plant PP Woven Bags PE Film
Price:
$7,750.00/sets >=1 sets
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
SANWEI
Product Description
Product Description
HDPE LDPE LLDPE washing plant plastic PP woven bags PE film washing recycling machine line
Material: Plastic Bag, PP Woven Bag, Plastic Film, Agricultural film, Plastic garbage etc.
Finished product: clean and dry plastic flakes
Flake size: 30-40mm or customized
Working Process:
1. Material Conveying → 2. Crushing → 3. Friction Washing and Loading→ 4. Flotation Washing → 5. 2nd Flotation Washing → 6. Drying → 7. Product Collecting
Description
This PP/PE flakes washing and drying line is suitable for high capacity. It is a whole line consists conveyor , crusher, washing tank and dewatering machine. It is an automatic production line which produces high quality production.
Automatically works, conveying material, crushing, washing, drying.
We also have plastic film granulators, if you need it please contact with me.
HDPE LDPE LLDPE washing plant plastic PP woven bags PE film washing recycling machine line
Plastic crusher with conveyor and friction washing machine
Floating washing tank
Plastic crushing washing recycling machine
plastic granulator
|
S / N
|
Item Name
|
Function
|
|
1
|
Conveyor
|
Feeding material
|
|
2
|
Crusher
|
Crushing the material into small size
|
|
3
|
Friction Washing Machine
|
Washing out the sand, soil and loading the material
|
|
4
|
Floating Washing Tank
|
Floating washing separate the sand,soil and other dirties
|
|
5
|
2nd Floating Washing Tank (self-selection)
|
Floating washing separate the sand,soil and other dirties
|
Plastic crusher with conveyor and friction washing machine
Details Images
PP PE Plastic recycling machine
capacity: 500kg/h (we still have more)
Conveyor
Delivery length: 4m
Motor power: 1.5kw
Speed: 25r/min
Can be customized.
Plastic crushing machine with friction washing machine
Crusher: 450type
Motor power: 22kw
rotary blade: 3pcs
stationary blade: 2pcs
Friction washing machine: L: 2.5m, D: 273mm
motor power: 7.5KW
Can be customized.
Floating washing tank
L * W * H: 8 m * 1.2 m * 1 m
Kick-out device: 3pcs
Vertical material lift dryer: 1pc
Vertical material lift dryer: 1pc
Motor power: 7.5KW.
Can be customized.
Can be customized.
Horizontal dewatering machine
Cylinder diameter: 700mm
Effective length: 2500mm
Motor power: 22kw
Speed: about 1200rpm
Dehydration rate: not less than 80%
Production capacity: 800-1000kg/h
Effective length: 2500mm
Motor power: 22kw
Speed: about 1200rpm
Dehydration rate: not less than 80%
Production capacity: 800-1000kg/h
Plastic Machinery :
Plastic granulators , Plastic crushing machine , Plastic crushing machine with friction washing machine, Baling press machine .
Plastic recycling machine, PET recycling machines , Recycle washing line, PP PE crushing washing dewatering and baling product line .
Plastic auxiliary machine and so on.
Technical Parameters
|
Model
|
Capacity
|
Conveyor
|
Crusher's model
|
Friction washing machine
|
Floating tank's model
|
||||
|
SW-500
|
500kg/h
|
L: 4m, W: 0.4m
|
450 , motor power: 22kw
|
L: 2.5m, D: 273mm
|
L: 8m, W: 1.2m, H: 1m
|
||||
|
SW-1000
|
1000kg/h
|
L: 6m, W: 0.5m
|
600 , motor power: 30kw
|
L: 2.5m, D: 377mm
|
L: 8m, W: 1.2m, H: 1m
|
||||
|
SW-2000
|
2000kg/h
|
L: 6m, W: 0.6m
|
800 , motor power: 45kw
|
L: 3m, D: 377mm
|
L: 8m, W: 1.2m, H: 1m
|
||||
|
SW-2500
|
2500kg/h
|
L: 6m, W: 0.8m
|
1000 , motor power: 55kw
|
L:3.5m, D: 420mm
|
L:8m, W: 1.2m, H: 1m
|
||||
|
Remarks
|
It can be customized to meet your requirement
|
|
|
|
|
||||
