Kl6ex Coal Mining LED Cap Lamp Atex Approved
KL6Ex mine safety underground helmet lamp battery is 6Ah
ATEX No.: Baseefa09ATEX0205-Issue 3KL6Ex miner cap lamp passed ATEX(Ex ia I M1) certification by Baseefa in England, can be used in mines with explosive atmospheres and occurrence of combustible dust and other flammable and explosive environment such as chemical industry, oil and road transportation.
Current-limiting resistance, quick-melting fuse, overcurrent and overheat protective device built in headpiece make lamp work safely.
Lamp body adopts ABS, 1 main light for working, 4 auxiliary lights for emergency lighting.
Standard:
EN 60079-0: 2012;
EN 60079-11: 2012;
EN 62013-1:2011;
EN 50303:2000;
| Battery capacity | 6Ah | |
| Rated voltage | 3.7V | |
| Battery type | Lithium ion | |
| LED light source | 1 main light + 4 auxiliary lights | |
| Working time | Main light | > 17 hours |
| Auxiliary light | > 50 hours | |
| Illumination at 1m apart from the lamp | Lighting begin | ≥7500Lux |
| After 11 hours | ≥7000Lux | |
| Lamp material | ABS + stainless steel | |
| Cable length | 1.45m | |
| Cap lamp lifespan | 2 years | |
| Charging time | < 10 hours | |
| Charging voltage | (6~8)V | |
| Charging cycle | > 800 cycles | |
| Explosion protection type | Ex ia I Ma, | |
| Ingress protection | IP65 | |
| Size | Headpiece: Φ71×75 mm, Battery pack: (72*65*18)mm | |
| Lamp weight | 650g | |
We offer different charging devices for one, ten and eighty units: KZC1B, KZC10A, KZC80A.
Single charger KZC1B
10 Units charger rack KZC10A
80 Units charger rack KZC80A
Shaanxi Asttar Explosion-proof Safety Technology Co., Ltd. is an ISO9001:2008 Certified company, the factory locates in Xi'an, central of China.
There are more than 50 experienced engineers and 100 practiced workers make it possible that supply services and equipment with quality standards at national and international level to mining sector, we trade as "GOKANG" since the year 1995, and changed to "ASTTAR" in 2017.
1. The products include:
LED cap lamps;
Rescue device: Self-rescuers, breathing apparatus;
Poisonous gas detectors, sensors;
Monitoring system.
2. 24*7 Online Service: We will answer you shortly once inquiry received.
3. More than 100 skillful workers make sure your order is finished quickly, more than 50 engineers supply professional Pre and After sales.
