Zyx45 (A) Reusable 45 Minutes Duration Escape Respirator Compressed Oxygen Self Rescuer
Product Description
ASTTAR ZYX45(A) reusable 45 minutes duration escape respirator, breathing apparatus,respiratory safety equipment, isolated compressed oxygen self rescuer
Application
It is a breathing apparatus, which utilizes compressed oxygen as source to form isolated oxygen of closed circuit to provide the wearer with clean oxygen, and is mainly used under a mine or in the environment where toxic gases exist or oxygen is deficient.
Items | Specification | |
ZYX45(A) | ||
Rated protective time | ≥45min | |
Capacity of oxygen bottle | 0.4L | |
Filling pressure for oxygen bottle | 19-21 MPa | |
Oxygen storage capacity | ≥80L | |
Inhalation oxygen concentration | ≥25% (by volume) | |
Inhalation carbon dioxide concentration | ≤2.0% (by volume) | |
Inhaling temperature(at the ambient temperature of 20ºC±3ºC) | <50ºC | |
Oxygen-supplying modes | Quantitative oxygen supply | >1.2L/min |
Oxygen delivery by demand valve | >60L/min | |
Oxygen delivery by manual switch | >60L/min | |
Opening pressure of safety valve | ≤ 1Mpa | |
Opening force of sealing belt | 40-120N. | |
Automatic opening pressure of automatic supply valve | (-100~-400)Pa | |
Exhaust pressure | 150 Pa~300Pa | |
Dimensions | (244×183×102)mm | |
Weight | 2.3kg | |
